SERVICE AND NETWORK DISCOVERY

Lesson Number: 112-CCTC18

Cyber



Table of Contents

7.0 Outcomes

  • Describe Methods Used for Passive External Discovery

    • Dig, Whois and Other Tools

      • Dig

      • Whois

      • Zone Transfer

    • Netcraft

    • Collect Historical Content

    • Google Searches

    • SHODAN

    • Passive OS Fingerprinting (p0f)

  • Describe Methods Used for Active External Discovery

    • Network Scanning and Banner Grabbing

      • PING

      • NMAP

      • Netcat

      • Curl and Wget

      • /dev/tcp

  • Describe Methods Used for Passive Internal Network Reconnaissance

    • Packet Sniffers

    • Native Host Tools

  • Describe Methods Used for Active Internal Network Reconnaissance

    • ARP Requests

  • Perform Network Forensics

    • Map a Network Through Correlation of Relevant Network Artifacts Gathered Through Reconaissance and Analysis


7.0.1 Section Introduction

Reconnaissance is the first step in a cybersecurity assessment, typically in the form of a penetration test or ethical hacking exercise, where the goal is to gather information about a target system or network.

As a defender it is important to know what systems, OS’s, and services are on the network along with normal communication patterns.

As an attacker, discovery of systems and services is crucial to formulating a plan of attack. An attacker spends 90 percent of their time performing reconnaissance and 10 percent of their time performing an actual attack.

There are four general approaches to Network Reconnaissance; Active External, Active Internal, Passive External and Passive Internal.


References:


Instructor Note

Instructor Notes.


7.0.1.1 Active vs Passive

Passive:

  • Passive reconnaissance involves gathering information about a target system, network, or organization without directly interacting with it.

  • On the offensive side, the client listens for beacons and other traffic sent periodically by a target. On the defensive side, passive scanning can be done using an IDS, it watches the network and look for irregular traffic or other indicators of compromise. A passive scan generally takes more time, since the client must listen and wait for traffic versus actively probing.

    • Publicly Available Information (PAI): Refers to data that is freely accessible to the public. This information can be found through various sources, both online and offline, and is not considered private or confidential.

    • Open Source Intelligence (OSINT): This involves gathering intelligence from publicly available sources. It involves collecting and analyzing data from publicly accessible resources such as websites, social media, public records, and other online repositories without directly interacting with or engaging the target systems.

      • OSINT sources can be divided up into six different categories of information flow:

        • Media:, print newspapers, magazines, radio, and television from across and between countries.

        • Internet, online publications, blogs, discussion groups, citizen media (i.e. – cell phone videos, and user created content), YouTube, and other social media websites (i.e. – Facebook, Twitter, Instagram, etc.). This source also outpaces a variety of other sources due to its timeliness and ease of access.

        • Public Government Data, public government reports, budgets, hearings, telephone directories, press conferences, websites, and speeches. Although this source comes from an official source they are publicly accessible and may be used openly and freely.

        • Professional and Academic Publications, information acquired from journals, conferences, symposia, academic papers, dissertations, and theses.

        • Commercial Data, commercial imagery, financial and industrial assessments, and databases.

        • Grey literature, technical reports, preprints, patents, working papers, business documents, unpublished works, and newsletters.

    • Network Traffic Analysis: Passive network traffic analysis involves monitoring network traffic passively to gather information about the target network. This can include analyzing network packets, monitoring DNS traffic, and observing patterns of communication to identify hosts, services, and potential vulnerabilities.

    • Domain Name System (DNS) Analysis: DNS reconnaissance involves gathering information about domain names, IP addresses, and other DNS records associated with the target organization. This can include querying DNS servers for information, performing zone transfers, and analyzing DNS cache data to gather intelligence about the target’s infrastructure.

    • WHOIS Lookup: WHOIS is a protocol used to query databases of registered domain names and IP addresses. WHOIS lookup tools can be used to gather information about domain ownership, registration dates, contact information, and other details that may be useful for reconnaissance purposes.

    • Passive DNS Analysis: Passive DNS analysis involves collecting and analyzing historical DNS data to identify patterns of domain ownership, domain associations, and changes in DNS records over time. Passive DNS databases can be queried to gather intelligence about domain names, IP addresses, and hostnames associated with the target organization.

    • Google Dorking: Google Dorking (also known as Google hacking) involves using advanced search techniques and operators to uncover sensitive information, files, or vulnerabilities exposed on the internet. By crafting specific search queries, attackers can discover publicly accessible documents, directories, login pages, and other resources that may contain valuable information about the target.

Active:

  • Active reconnaissance refers to the proactive and deliberate exploration of a target network or system to gather information.

  • Active scanning is the process of transmitting packets to a remote host and analyzing corresponding replies to locate and identify devices.

    • Port Scanning: This involves scanning the target system for open ports and services. Tools like Nmap are commonly used for this purpose. Knowing which ports are open can provide insight into the services running on the system and potential vulnerabilities.

    • Network Scanning: This involves scanning the target network for devices and their characteristics. Tools like NetScanTools or Angry IP Scanner can be used to identify hosts, their IP addresses, and other network information.

    • Vulnerability Scanning: This involves scanning for known vulnerabilities in the target system or network. Tools like Nessus or OpenVAS can automatically scan for vulnerabilities in systems and provide reports on potential weaknesses.

    • DNS Enumeration: This involves gathering information about the domain name system (DNS) of the target organization. Tools like nslookup or dig can be used to query DNS servers for information such as hostnames, IP addresses, and mail exchange (MX) records.

    • Web Application Scanning: This involves scanning web applications for vulnerabilities such as SQL injection, cross-site scripting (XSS), or directory traversal. Tools like Burp Suite or OWASP ZAP can be used to scan web applications for security flaws.

    • Social Engineering: While not strictly a technical method, social engineering involves manipulating individuals within the target organization to divulge sensitive information. This can include techniques such as phishing, pretexting, or impersonation.

Internal:

  • Internal reconnaissance, also known as internal scanning or internal network reconnaissance, involves gathering information about a target network from within the network itself.

  • This phase typically occurs after an attacker has gained some level of access to the internal network, either through social engineering, phishing, malware, or exploiting vulnerabilities in external-facing systems.

  • Internal reconnaissance is crucial for attackers seeking to escalate privileges, move laterally within the network, and identify high-value targets.

  • It’s also an essential step in red teaming exercises and security assessments conducted by organizations to evaluate the security posture of their internal networks.

External:

  • External reconnaissance, also known as external scanning or external network reconnaissance, involves gathering information about a target network from outside the network perimeter.

  • This phase is typically the first step in a cyber attack or security assessment and is aimed at identifying potential entry points, vulnerabilities, and attack surfaces.

  • External reconnaissance is crucial for attackers seeking to gain initial access to a target network and for organizations conducting security assessments to identify and mitigate external threats.


800


External

Internal

Passive

* PAI/OSINT
* DNS Lookups (DIG)
* Whois
* Job site listings
* Shodan

* Packet Sniffing
* ARP Cache
* IP Address
* Running Services
* Open Ports

Active

* Ping scans
* NMAP scans
* Port Scans
* OS Identification

* DNS Queries
* ARP Requests
* Ping Scans
* Port Scans
* Network Scanning

  • Passive recon - is when you gather information about a target without directly interacting with the target. In networking it means to gather information about a target without sending packets to the target. Target is not likely to generate logs or artifacts to inform them they are being targeted.

    • Publicly Available Information (PAI) / Open source intelligence (OSINT) to gather:

      • IP addresses

      • domain names

      • email addresses

      • names

      • hostnames

      • dns records

      • software running (to associate with CVE)

    • Using tools like:

      • Google Hacking (search engines)

      • Netcraft

      • Shodan

      • Social Media

      • DNS

  • Active recon - is when you interact directly with a computer system in order to gather system specific information about the target. In networking it means to gather information about a target by sending packets to the target in order to solicit information. Target with potentially generate logs and create artifacts. The main drawback of active reconnaissance compared to passive reconnaissance is that direct interaction with the host has a chance of triggering the systems IDS/IPS and alerting people to your activity.

    • Used to find out information such as:

      • open/closed ports

      • OS of a machine

      • services running

      • banner grabbing

      • discovering new hosts

      • find vulnerable applications on a host

    • Using tools like:

      • Nmap

      • Ping

      • Traceroute

      • Netcat

      • Nessus

      • Nikito


References:


Instructor Note

Instructor Notes.


7.0.1.2 Blue vs Gray vs Red Space

In network reconnaissance and cybersecurity, the terms Blue, Gray, and Red Spaces represent different environments or domains that relate to how information is gathered, protected, or attacked. These spaces are central concepts in understanding how both defenders (Blue Teams) and attackers (Red Teams) interact with networks, systems, and the public domain during security assessments.


bgr space


  1. Blue Space (Friendly Space)

    • Definition: The Blue Space is your trusted network or the environment you control. This could be your organization’s internal network or the systems, servers, and infrastructure you are responsible for protecting.

    • Role in Reconnaissance: When conducting reconnaissance from a Blue Space, you are operating within a trusted environment, meaning you have access to resources that allow you to perform defensive operations (e.g., vulnerability scanning, network monitoring, or internal threat hunting) without the risk of breaching security protocols.

    • Examples of Activities:

      • Internal network scans: You may use internal tools to scan your infrastructure for vulnerabilities.

      • Internal logs monitoring: Reviewing system logs or using SIEM to detect any suspicious activity within the network.

      • Assessing known assets: Checking for misconfigurations, weak access controls, or outdated systems that could be exploited by an attacker.

    • Goal: To secure the environment by identifying potential security flaws, detecting insider threats, and ensuring that no unauthorized activities are occurring in the friendly space.

  2. Gray Space (Public Internet)

    • Definition: The Gray Space refers to the public internet or untrusted networks that exist outside of your control. This is where you will gather information that is publicly available, such as websites, DNS records, IP addresses, and other external-facing assets.

    • Role in Reconnaissance: In the Gray Space, you engage in open-source intelligence (OSINT) gathering and other forms of external reconnaissance. It’s a space where both attackers and defenders operate to learn about target organizations, and it’s the neutral ground between your controlled environment (Blue) and the potential adversary (Red).

    • Examples of Activities:

      • OSINT gathering: Collecting information from public sources like social media, WHOIS records, and company websites to understand your target.

      • Passive scanning: Identifying and mapping the organization’s internet-facing assets like IP addresses, subdomains, and exposed services without interacting directly with the target systems.

      • Third-party services: Looking into security breaches, leak databases, or other third-party databases that might contain information about your target.

    • Goal: To gather public information and intelligence about your target or organization, but without interacting directly with the target in a way that could alert them to your activities. In this phase, the aim is to understand what’s exposed to the outside world.

  3. Red Space (Target Space)

    • Definition: The Red Space is the target network or adversarial environment. It is the environment that you, as the attacker (or ethical hacker), are trying to penetrate or gather intelligence on.

    • Role in Reconnaissance: When in the Red Space, you are operating with the intent to discover vulnerabilities, gather more detailed intelligence, or map out the target system’s weaknesses. This space is where active penetration testing, scanning, and potentially exploiting vulnerabilities occurs.

    • Examples of Activities:

      • Active scanning: Using tools like Nmap or Nessus to actively scan a target for open ports, services, and vulnerabilities that could be exploited.

      • Service enumeration: Identifying which services (e.g., web servers, mail servers) are running on the target’s network and gathering information about them to identify weaknesses.

      • Exploitation: Attempting to exploit discovered vulnerabilities (e.g., weak services, misconfigured systems) to gain unauthorized access.

    • Goal: To compromise the target network by identifying entry points, executing attacks, and potentially exfiltrating data, either for offensive purposes (as an attacker) or for ethical hacking purposes (as a penetration tester).


References:


Instructor Note

Instructor Notes.


7.0.2 Network Footprinting, Scanning, Enumeration, and Vulnerability Assessment

Network footprinting, scanning, enumeration, and Vulnerability Assessment are essential steps in the reconnaissance phase of a cybersecurity assessment or attack. Each step involves gathering information about a target network to understand its structure, devices, services, and potential vulnerabilities.


References:

Penetration Testing Standard(PTES)
OSINT Framework
Malfrat’s OSINT Map
Mark@OSINT-Research pages Security Sift Passive Resonnaissance
Your OSINT Graphical Analyzer (YOGA)
Mindmaps
Awesome OSINT For Everything
Open-Source Intelligence (OSINT) in 5 Hours - Full Course - Learn OSINT!


Instructor Note

Instructor Notes.


7.0.2.1 Network Footprinting

Network footprinting involves gathering information about a target network’s infrastructure, organization, and digital footprint. This information helps attackers or security professionals understand the scope and layout of the network.

This is the process of collecting information related to our target

  • Network - information related to the target network

    • DNS Domain Name

    • DNS Sub-domains

    • IP address blocks

    • Firewall/IDS/IPS discovery

    • External/Internal Websites

    • TCP/UDP services

    • VPN endpoints

    • Network Protocols

  • Systems - information related to the target system(s)

    • Hostname

    • IP/MAC address

    • User accounts

    • Group accounts

    • System Banners

    • Routing Tables

    • ARP Cache

    • SNMP data

  • Organization - information related to the target organization

    • Employees

    • Email addresses

    • Phone Numbers

    • Organization website

    • Security Policies

    • Org Charts


References:


Instructor Note

Instructor Notes.


7.0.2.2 Network Scanning

Scanning involves actively probing the target network to identify live hosts, open ports, and services running on those ports. This phase aims to discover potential entry points and vulnerabilities.

  • Port Scanning - open TCP/UDP ports and services

  • Network Scanning - Ip addresses, Operating systems, Network topology and Network devices

  • Vulnerability Scanning - scanning/detecting known vulnerabilities or weaknesses.


References:


Instructor Note

Instructor Notes.


7.0.2.3 Network Enumeration

Enumeration involves extracting more detailed information about the target network, such as user accounts, shares, applications, and configurations. This phase aims to gather as much information as possible to plan further attacks or security measures.

  • Types of information enumerated

    • Network Resource and shares

    • Users and Groups

    • Routing tables

    • Auditing and Service settings

    • Machine names

    • Applications and banners

    • SNMP and DNS details

    • Other common services and ports


References:


Instructor Note

Instructor Notes.


7.0.2.4 Vulnerability Assessment

Vulnerability assessment is a systematic process of identifying, quantifying, and prioritizing security vulnerabilities in a system, network, or application. It’s a critical component of cybersecurity risk management and helps organizations understand their exposure to potential threats.

Process of indetifying vulnerabilities on a system, network or communication channels. Some of the top 10 vulnerabilities according to Open Web Application Security Project (OWASP) to look for are:

  1. A01: Broken Access Control

    • Description: Improper implementation of access control can result in unauthorized data viewing, modification, or deletion.

    • Example: A user can access another user’s account information by manipulating URL parameters.

    • Prevention:

      • Implement strong authorization mechanisms.

      • Enforce least privilege principles.

      • Regularly review and update access controls.

  2. A02: Cryptographic Failures

    • Description: Weakly configured or poorly implemented cryptography can lead to data breaches.

    • Example: A web application uses a weak encryption algorithm for transmitting sensitive data, making it susceptible to eavesdropping.

    • Prevention:

      • Use strong cryptographic algorithms and protocols.

      • Protect cryptographic keys securely.

      • Regularly review and update cryptographic implementations.

  3. A03: Injection

    • Description: Injection flaws occur when untrusted data is sent to an interpreter as part of a command or query.

    • Example: A user can inject malicious SQL code into an input field to access or modify database content (SQL injection).

    • Prevention:

      • Input validation and sanitization.

      • Prepared statements or parameterized queries.

      • Output encoding.

  4. A04: Insecure Design

    • Description: Weak security requirements as part of the software development lifecycle can lead to system failures.

    • Example: A web application exposes sensitive data in error messages, allowing attackers to gather information for further attacks.

    • Prevention:

      • Threat modeling and risk assessment.

      • Secure by design principles.

      • Security code reviews.

  5. A05: Security Misconfiguration

    • Description: Improper security configurations in software, frameworks, and hardware can lead to information disclosure, takeover, or data loss.

    • Example: A web server is configured with default credentials, allowing unauthorized access.

    • Prevention:

      • Follow security best practices for configurations.

      • Use security configuration checklists.

      • Regularly review and update configurations.

  6. A06: Vulnerable and Outdated Components

    • Description: Using components with known vulnerabilities can lead to exploitation.

    • Example: A web application uses an outdated version of a popular library with known vulnerabilities, leading to a successful exploit.

    • Prevention:

      • Maintain up-to-date component inventories.

      • Regularly check for vulnerabilities.

      • Implement a patch management process.

  7. A07: Identification and Authentication Failures

    • Description: Improper implementation of identification and authentication functions can allow attackers to compromise accounts.

    • Example: A web application allows weak passwords or lacks proper session management, enabling account takeover.

    • Prevention:

      • Strong password policies and multi-factor authentication.

      • Secure session management.

      • Protect authentication data.

  8. A08: Software and Data Integrity Failures

    • Description: Failures in software and data integrity can result in unexpected behavior, data corruption, or denial of service.

    • Example: A web application fails to verify the integrity of uploaded files, allowing attackers to inject malicious code.

    • Prevention:

      • Code signing and verification.

      • Data integrity checks.

      • Secure software updates.

  9. A09: Security Logging and Monitoring Failures

    • Description: Insufficient logging and monitoring can increase the time to identify and respond to incidents.

    • Example: A web application lacks adequate logging, making it difficult to detect and respond to security incidents.

    • Prevention:

      • Comprehensive logging and monitoring.

      • Real-time threat detection.

      • Incident response plan.

  10. A10: Server-Side Request Forgery (SSRF)

    • Description: Improper handling of user-supplied input can lead to an attacker accessing internal systems through the application.

    • Example: A web application allows users to specify arbitrary URLs, enabling attackers to access internal systems through the application.

    • Prevention:

      • Input validation and sanitization.

      • Restrict allowed hosts and ports.

      • Avoid exposing internal systems to untrusted input.


References:

https://owasp.org/www-project-top-ten/


Instructor Note

Instructor Notes.


7.1 Describe Methods Used for Passive External Discovery


800


Passive host and service discovery is much less straight forward and requires more time than active discovery methods, but it carries less risk of discovery by administrators and Network System Monitoring "NSM" (IPS/IDS). Passive approaches require knowledge of particular systems, their nuances, and how they generate network traffic. In general, the passive reconnaissance approach can be categorized as attempted gathering of information about a target network or host without direct interaction.

Network owners must understand what information can be gleaned from their network traffic and have a full understanding of their network footprint. Information can be gathered from a target passively by eavesdropping on a target using tools such as Wireshark, tcpdump, and tshark.

Performing passive reconnaissance typically involves identifying key topics across several specific areas. To maintain anonymity and avoid revealing our true identities during this process, it is essential to operate under a credible and realistic false persona. This is achieved through the creation and use of a well-crafted 'sock puppet'—a fictitious online identity designed to blend seamlessly into the digital environment while ensuring operational security.


  • Creating a Sock Puppet

    • An OSINT sock puppet is a fabricated online persona designed specifically for conducting Open-Source Intelligence (OSINT) investigations discreetly. It is used to gather publicly available information or interact with individuals, groups, or communities without revealing the operator’s true identity. These accounts are carefully crafted to appear authentic and avoid suspicion.

    • Characteristics of an OSINT Sock Puppet:

      • Detailed Persona:

        • Includes a realistic name, date of birth, gender, and location. (https://www.fakenamegenerator.com/)

        • A consistent background story that aligns with the account’s activity and purpose.

      • Visual Identity:

        • A profile picture that looks authentic but isn’t tied to a real person. Tools like AI-generated images (e.g., from platforms like https://www.thispersondoesnotexist.com/) are often used.

        • Posts include real-looking images (e.g., landscapes, objects) rather than personal photos.

      • Digital Presence:

        • Active and believable engagement across multiple platforms (e.g., Twitter, Facebook, LinkedIn, Instagram).

        • Posts reflect normal online behavior, such as sharing news, memes, or personal interests.

      • Engagement and Relationships:

        • Follows other accounts, joins groups, or participates in discussions relevant to the investigation.

        • May develop relationships with targets to gain trust and access information.

      • Operational Security (OPSEC):

        • Avoids linking back to the operator’s real identity (e.g., using a VPN, separate devices, or virtual machines).

        • The account does not use names, images, or content that could compromise the operator.

        • Regularly updated to prevent being flagged as inactive or fake.

      • Specialized Purpose:

        • Targeted to a specific community, language, or interest group based on the investigation’s goals.

        • Examples include engaging with extremist forums, monitoring corporate competitors, or researching disinformation campaigns.

      • Ethical and Legal Considerations:

        • Using sock puppets raises ethical questions and legal risks, particularly when engaging with individuals or groups under false pretenses. Organizations conducting OSINT often follow strict guidelines to ensure compliance with laws and avoid manipulation or misuse of data.


References:

Penetration Testing Standard(PTES)
OSINT Framework
Malfrat’s OSINT Map
Mark@OSINT-Research pages
Security Sift Passive Resonnaissance
Your OSINT Graphical Analyzer (YOGA)
Mindmaps
Awesome OSINT For Everything
Open-Source Intelligence (OSINT) in 5 Hours - Full Course - Learn OSINT!
The Ultimate Guide to Sockpuppets in OSINT: How to Create and Utilize Them Effectively
Fake Name Generator
This Person does not exist


Instructor Note

Ask the students for examples of items of interest when performing passive reconnaissance


7.1.1 Passive Recon Activities

Passive reconnaissance, commonly known as "passive recon" or "passive information gathering," entails the collection of information about a target without direct engagement with its systems. The objective is to quietly acquire data without triggering any alerts from the target. Open source intelligence (OSIT) gathering is most commonly used in this phase. This phase is crucial in cybersecurity assessments, ethical hacking, and penetration testing processes. A cornerstone of OSINT is collecting Publicly Available Information (PAI).

Open-Source Intelligence (OSINT) - Is the process of collecting and analyzing publicly available information to produce actionable intelligence.

Publicly Available Information (PAI) - Is any data that is accessible to the general public. It’s a broad term encompassing a wide range of information found in various public sources.

  • PAI sources can be divided up into different categories of information flow:

    • Offline:

      • Traditional Media: Newspapers, magazines, television, and radio broadcasts.

      • Public Records: Government offices maintain records like birth, death, marriage, property, and court records.

      • Libraries: Physical and digital collections of books, articles, and research materials.

      • Public Events: Conferences, speeches, and demonstrations can provide valuable insights.

    • Online (Internet):

      • Social Media: Platforms like Facebook, Twitter, Instagram, LinkedIn, TikTok, etc., offer a wealth of user-generated content.

      • Search Engines: Google, Bing, and other search engines provide access to billions of web pages.

      • News Websites and Blogs: Online publications offer news, opinion, and analysis.

      • Government Websites: Government agencies publish data, reports, and regulations.

      • Company Websites: Corporate information, press releases, and investor relations materials.

      • Online Forums and Communities: Platforms like Reddit, Quora, and specialized forums offer discussions and information sharing.

      • Video and Image Sharing: Sites like YouTube, Flickr, and others host multimedia content.

      • Image-sharing platforms (Google Images, Flickr, etc.)

      • Open Data Portals: Government and non-profit organizations often release datasets for public use.

      • The Deep Web and Dark Web: While more challenging to access, these can contain valuable information, but proceed with caution.

    • Public Data:

      • Government agencies (birth, death, marriage records, property records, etc.)

      • Public government reports, budgets, hearings, telephone directories, press conferences, websites, and speeches. Although this source comes from an official source they are publicly accessible and may be used openly and freely.

      • Professional and Academic Publications, information acquired from journals, conferences, symposia, academic papers, dissertations, and theses.

    • Commercial Data:

      • Market research reports: Published findings can provide insights into consumer behavior, market trends, and industry performance.

      • Economic indicators: GDP, inflation rates, unemployment figures, and other economic data are widely available.

      • Weather data: Commercial weather services provide publicly accessible forecasts and historical data.

      • Satellite imagery: Commercial satellite companies offer imagery that can be used for various purposes.

    • Grey literature:

      • Government reports on economic indicators, population trends, or environmental impact assessments.

      • Industry whitepapers on market analysis, technology trends, or best practices.

      • Think tank reports on policy recommendations and social issues.

      • Conference proceedings with research findings and industry insights.

      • Technical reports, preprints, patents, working papers, business documents, unpublished works, and newsletters.


References:

http://www.pentest-standard.org

https://osintframework.com/

https://www.securitysift.com/passive-reconnaissance/


Instructor Note

Instructor Notes.


7.1.1.1 IP Addresses and Sub-domains

Usually one of the first steps in passive reconnaissance, it’s important to identify the net ranges and sub-domains associated with your target(s) as this will help scope the remainder of your activities.


References:

https://github.com/ninoseki/mitaka


Instructor Note

Instructor Notes.


7.1.1.2 Identifying External/3rd Party sites

  • This is not typically in the scope for penetration testing but should not be overlooked as advesaries can (and do) expoit this.

  • This involves external companies that support or collaborate with your target. These may have softer security.

  • Target’s competitors may have details about your target that they collected for themselves.

  • Look for potential supply chain attack.


References:

https://en.wikipedia.org/wiki/Supply_chain_attack

https://gbhackers.com/cryptocurrency-miner-ubuntu-snap-store/

https://www.radware.com/blog/security/2018/05/nigelthorn-malware-abuses-chrome-extensions/

https://www.helpnetsecurity.com/2019/07/18/malicious-python-packages/


Instructor Note

Instructor Notes.


7.1.1.3 Identifying People

Identifying names, email addresses, phone numbers, and other personal information can be valuable for pretexting, phishing or other social engineering activities. Use open-source to collect information on subject browse social media sites:


References:


Instructor Note

Instructor Notes.


7.1.1.4 Identifying Technologies

Identifying the types and versions of the systems and software applications in use by an organization is an important precursor to identifying potential vulnerabilities. You can ID technologies from many sources including:

  • File extensions ( https://www.computerhope.com/issues/ch001789.htm ) - many are specific to certain applications operating systems

  • Server responses - Various tools can identify specific signatures in network traffic.

  • MAC OUI lookups:

  • Job postings/interviews

  • Directory listings on the target webpage

    Login splash pages

  • Website content

  • Content-Types

    • Server Software and Version

    • Cookie Information

    • Builtwith - detect which technologies are used on any website on the internet.

    • Tools:

      • wget

      • HTTrack

      • Pavu

      • WebRipper 2.0 (www.calluna-software.com)

      • WinWSD

      • DomainPunch

      • WebExtractor

  • Public acquisition records

  • Shodan.io

  • Spyse - is another OSINT search engine that lets anyone grab critical information about any website in the world. Quite simply, Spyse is an infosec crawler that gets useful information for red and blue teams during the reconnaissance process.

  • Document Searches

  • Google Hacking - Database

    • https://dorksearch.com/

    • Google dork cheatsheet

      • site:

        site:.gov "Secret"
site:linkedin.com intitle:starbucks "network engineer"

      • intitle:

        intitle:"Welcome to Windows 2000 Internet Services"
intitle:"Nessus Scan Report" "This file was generated by Nessus"
intitle:"index of" inurl:ftp

      • inurl:

        inurl:admin/login
inurl:/admin.html

      • filetype:

        filetype:pdf "Confidential"
filetype:ppt "Networking"

  • System fingerprinting tools:

    • Ettercap – passive TCP/IP stack fingerprinting.

    • NetworkMiner – passive DHCP and TCP/IP stack fingerprinting (combines p0f, Ettercap and Satori databases)

    • p0f – comprehensive passive TCP/IP stack fingerprinting.

    • NetSleuth – free passive fingerprinting and analysis tool

    • PacketFence – open source NAC with passive DHCP fingerprinting.

    • PRADS – Passive Real-time Asset Detection System. Passive comprehensive TCP/IP stack fingerprinting and service detection

    • Satori – passive CDP, DHCP, ICMP, HPSP, HTTP, TCP/IP and other stack fingerprinting.

    • SinFP – single-port active/passive fingerprinting.

    • XProbe2 – active TCP/IP stack fingerprinting.

    • Device Fingerprint Website - Displays the passive TCP SYN fingerprint of your browser’s computer (or intermediate proxy)

  • File Metadata Tools:


References:


Instructor Note

Instructor Notes.


7.1.1.5 Identifying Content of Interest

Identifying web and email portals, log files, backup or archived files, or sensitive information contained within HTML comments or client-side scripts is important for vulnerability discovery and future penetration testing activities.

  • Site content can reveal potential access points (e.g. web portals), sensitive data (login credentials), and more. As you browse the site be on the lookout for the following:

    • Externally facing web portals, webmail, and administrative consoles - As you navigate the site, you will want to take note of any interesting functionality that could prove useful for future penetration testing activities such as externally-facing web portals, email services, or administrative consoles. It’s possible you might come across these as you browse but you may also want to look for them with targeted Google searches.

    • Test pages - Be on the lookout for test infrastructure as well. Often test pages have fewer security controls or robust error messages when compared to their production counterparts, yet they frequently reside on (and provide access to) the same production infrastructure.

    • Log files - Log files are sometimes left exposed and publicly accessible via Google search results. Logs can contain everything from robust errors to configuration data, IP addresses, usernames and even clear text passwords

    • Backup files - Sometimes web admins retain old, possibly vulnerable versions of website pages or text versions of server-side code (php, asp, etc) that can be downloaded and reviewed offline.

    • Configuration files - Configuration files can contain sensitive connection strings, passwords, IP addresses and other valuable information.

    • Database dump files - Similar to configuration files, database dump files can contain sensitive information such as table structures and queries (for use in SQL injection testing), names, email addresses, usernames, and passwords. Searching for filetypes of sql, dbf, mdf, dat, or mdb (among others) can uncover these files.

    • Client-side code - Review of client-side HTML and scripts can reveal sensitive data or even vulnerabilities such as unsafe handling of user-provided data. BurpSuite Pro has an engagement tool called “Find Scripts” which will search the specified hosts(s) in your site map and extract content for review.

    • /etc/passwd and /etc/shadow or SAM database

      • Windows usually stores passwords in these locations:

        • Security Accounts Manager (SAM) database (C:\WINDOWS\system32\config) or (HKEY_LOCAL_MACHINE\SAM)

        • SAM file is not accessible while the OS is running. Use an external bootable CD or USB.

        • Active Directory database file that’s stored locally or spread across domain controllers (ntds.dit)

        • hashes passwords with NTLM

      • Linux and other UNIX variants typically store passwords in these files:

        • /etc/passwd (readable by everyone) - Contains the usernames

        • /etc/shadow (accessible by the system and the root account only) - Contains the passwords.

        • /etc/security/passwd (accessible by the system and the root account only)

        • /.secure/etc/passwd (accessible by the system and the root account only)

        • hashes passwords with:

          • $1 = MD5

          • $2 =Blowfish

          • $2a=eksblowfish

          • $5 =SHA-256

          • $6 =SHA-512


References:


Instructor Note

Instructor Notes.


7.1.1.6 Identifying Vulnerabilities

It’s possible to identify critical vulnerabilities that can be exploited with further active penetration testing activities solely by examining publicly available information


References:

https://www.securitysift.com/passive-reconnaissance/


Instructor Note

Instructor Notes.


7.1.1.6.1 Compliance Auditing

Compliance auditing is a systematic examination wherein an organization’s conformity to regulatory guidelines, industry standards, and internal policies is scrutinized and assessed. The main objective is to verify that the organization is conducting its operations in alignment with relevant laws, regulations, and established protocols. The purpose of conducting compliance audits is to pinpoint any variances from the specified standards and initiate corrective measures when deemed necessary.

Compliance auditing standards refer to the established criteria and guidelines that organizations follow when conducting audits to assess their adherence to regulatory requirements, industry standards, and internal policies. These standards provide a framework for conducting thorough and effective compliance audits.

  • PCI DSS - Payment Card Industry Data Security Standard (PCI DSS) compliance is designed to protect businesses and their customers against payment card theft and fraud. If your business accepts, stores, or transmits card data, PCI DSS compliance validation is required by card brands such as Visa, MasterCard and Discover.

  • NERC - The North American Electric Reliability Corporation (NERC) Critical Infrastructure Protection (CIP) exists to improve the reliability of the critical bulk power SCADA systems that create and transport electricity around the continent, and the goal of a NERC compliance program is to ensure that the bulk electric system in North America is reliable, adequate and secure. It’s not enough to just plan for natural disasters or accidents-the bulk power system now must be planned, designed, built and operated in a manner that also takes into account modern threats to security, including attacks from cyber criminals. NERC compliance programs are required to help prevent these attacks.

  • FISMA - The Federal Information Security Management Act (FISMA) requires Federal agencies to develop, document, and implement an information security program to safeguard their systems and data. In addition to government agencies, FISMA also applies to contractors and third parties that use or operate an information system on behalf of a Federal agency.

  • SOX - Sarbanes-Oxley Act (SOX) requires that publicly-traded companies ensure their internal business processes are properly monitored and managed. Financial reporting processes are driven by IT systems, so IT needs to be configured securely and maintained properly. The Securities and Exchange Commission (SEC) has identified five areas that need to be addressed to meet SOX internal control requirements and support SOX compliance, two of which are risk assessment and monitoring.

  • GLBA - The Gramm-Leach-Bliley Act is a U.S. federal law created to control how financial institutions deal with a consumer’s non-public personal information (NPI). This is information that a financial institution collects when providing a financial product or service that can identify an individual and that isn’t otherwise publicly available.

    • The Act has three main elements:

      • The Privacy Rule, which regulates the collection and use of NPI

      • The Safeguards Rule, which requires financial institutions to implement a security program to protect NPI

      • Pretexting provisions, which prohibits access to NPI under false pretense

  • HIPAA - The Health Insurance Portability and Accountability Act (HIPAA) protects the privacy and security of personal health information (PHI). Any healthcare organization that stores, processes, or transmits PHI must meet HIPAA compliance requirements, including any business associates that perform functions or provide services on their behalf.

  • GDPR - The General Data Protection Regulation (GDPR compliance) protects the personal data of EU citizens regardless of the geographical location of the organization or the data. Organizations around the world must be compliant with GDPR by 25th May 2018. Changes to people, processes, and technology are required to ensure that personal data is correctly controlled, processed, maintained, retained, and secured. Penalties for infringement of the General Data Protection Regulation can be up to €20,000,000 or 4% of worldwide annual turnover, whichever is the greater amount.

  • CIS Benchmarks - The Center of Internet Security (CIS) is a non-for-profit organization that develops their own Configuration Policy Benchmarks, or CIS benchmarks, that allow organizations to improve their security and compliance programs and posture. This initiative aims to create community developed security configuration baselines, or CIS benchmarks, for IT and Security products that are commonly found throughout organizations.

  • SCAP - The Security Content Automation Protocol (SCAP) is a method that uses open standards to organize and express security-related information. It’s not a regulation or a mandate, but it allows federal agencies to automate a great deal of manual processes and make data standardization and comparisons a lot easier.

  • FDCC - The Federal Desktop Core Configuration (FDCC compliance) is an older federal standard that defines a standardized desktop configuration to improve security. Although FDCC benchmarks have been superseded by USGCB benchmarks in 2010 and 2011, many agencies are still working on their FDCC compliance. If you’re one of them, we can help you achieve FDCC compliance.

  • USGCB - The United States Government Configuration Baseline (USGCB) is a United States government-wide initiative that guides federal agencies on what they can do to improve and maintain effective configuration settings focusing primarily on security. This initiative aims to create security configuration baselines for IT and security products, specifically on desktops and laptops, deployed across federal agencies. While it’s not a standalone regulation like FISMA, USGCB compliance is a core requirement of FISMA.


References:


Instructor Note

Instructor Notes.


7.1.2 Dig, Whois and Other Tools

DNS is critical to the operation of the Internet for resolving hostnames to IP addresses. Therefore, DNS servers contain vast amounts of data that can be used to gain information.


References:


Instructor Note

Instructor Notes.


7.1.2.1 Whois

  • RFC 3912
    TCP-based transaction-oriented query/response protocol that is widely used to provide information services to Internet users. While originally used to provide "white pages" services and information about registered domain names, current deployments cover a much broader range of information services. The protocol delivers its content in a human-readable format.

  • The WHOIS lookup helps determine where the site is hosted, who owns the IP block, and may list organizational contacts that may be useful for social engineering.

  • WHOIS works by querying DNS registrars databases over TCP port 43.

  • Most whois queries will return false information as most people opt for privacy of their domain information in order to protect against email harvesting, spam, and social engineering attempts on the administrative contact.

instructor@net1:~$ whois ccboe.net

whois


References:

https://tools.ietf.org/html/rfc3912

https://manpages.debian.org/buster/whois/whois.1.en.html

https://www.cloudflare.com/learning/dns/glossary/what-is-a-domain-name-registrar/

https://en.wikipedia.org/wiki/Domain_name_registrar

https://www.wpbeginner.com/beginners-guide/how-to-choose-the-best-domain-registrar/


Instructor Note

Ask the students to identify answers to the questions below:#

What does ccboe stand for?#
Columbia County Board of Education
Who is the DNS registrar?#
Network Solutions, LLC
When does the domain registration expire?#
June 30, 2021
How many Name Servers are there?#
2, NS1.CL.BELLSOUTH.NET, NS2.CL.BELLSOUTH.NET
Who is the administrator?#
James Van Meter
What is the administrator’s email address?
hostmaster@ccboe.net
What is the administrator’s phone number?
1-706-541-2721
Where is the location of the technology department possibly located?
6430 Pollards Pond Road, Appling, GA 30802
Google Maps Link

  • It quickly becomes apparent that if not sanitized properly, a multitude of information can be gleaned from the whois query. Occasionally, net range is displayed with a CIDR and could prove useful for future DNS reverse lookups.

Should this be avoided and if so, how?
Register the domain with anonymous registration services under a pseudonym. Often times domain name registrars will offer whois privacy (also known as domain privacy) as a service that in turn replaces the user’s information in the WHOIS with information of the forwarding service aka proxy of the registrar.

How might these be used as an defense tool?
If your system is being scanned or attacked you can use a WHOIS to possibly begin determining where the source of the malicious traffic is coming from.


7.1.2.2 DIG

Dig is a tool that returns key DNS information and can be used to supplement the query for specific records.

instructor@net1:~$ dig ccboe.net
instructor@net1:~$ dig ccboe.net MX
instructor@net1:~$ dig ccboe.net SOA
instructor@net1:~$ dig ccboe.net TXT


dig1


dig2


This method can be further enhanced with tools such as dnsrecon that will brute-force with a word-list to find hidden sub-domains using words such as sales, training, admin, etc. This method is considered semi-active, generating logs for unlisted sub-domains would look quite suspicious.


References:

dig Man Page


Instructor Note

Ask the students to identify answers to the questions below:

Who is the SOA?

What type of mail server is listed?


7.1.2.3 Zone Transfers

A zone transfer is typical between primary and secondary DNS servers to update records on a domain. This information, if allowed to be transferred externally through misconfiguration, allows hostnames, IP’s, and IP blocks to be discovered. With this information, targets can be determined with information for possible social engineering.

instructor@net1:~$ dig axfr @nsztm1.digi.ninja zonetransfer.me
zonetransfer


DigiNinja’s Zone Transfer Me


References:


Instructor Note

Lead the students through a zone transfer using the following syntax:

This zone transfer includes tons of information, the website will guide you along and you may format questions based on what you see.+

What sub-domains have been found?
What mail servers are being used?
Can you determine location with the LOC file?


7.1.3 Netcraft

Netcraft.com can also be used to find extra information about a url, including the netblock owners and hosting history. The date first seen is December 1996 for "www.ccboe.net". Combine this with sites such as the wayback machine and see what you can come up with.

The key takeaway is that the traffic generated looks like normal DNS queries and the target is none the wiser that they are being probed for information. For further non attribution, use a third party web-site such as dns stuff or central ops to perform the queries.


References:

https://sitereport.netcraft.com/


Instructor Note

Go to the website below and walkthrough an example with the students:

Netcraft: www.ccboe.net

When was the domain first registered?

1996


7.1.4 Collect Historical Content

Organizations often change their associated websites over time. As more emphasis is placed on security, these organizations have made more and more of their information private over time. A company may have posted their organizational charts, contact information for important people and even device type specifics on their websites in the past. There are many organizations that take snapshots of pages over time and archive these results. The Wayback Machine is the most popular example of this and can be a useful tool if you are looking for information you know was hosted in the past, but is not available now.

  • Using the Wayback Machine, you can:

    • Track website changes: Search for the company’s domain on the Wayback Machine. This will show you archived versions of the website over time. You can identify changes in website content, design, or domain ownership. For instance, if the company used to have a different name or was involved in different activities, this information might be revealed in older versions of the website.

    • Discover removed content: Sometimes, companies delete information from their websites to cover their tracks. The Wayback Machine can uncover this deleted content, providing valuable clues.

    • Identify past associates: If the company has changed its leadership or partnerships, the Wayback Machine can help identify previous associates who might be relevant to your investigation.

    • Uncover hidden information: Wayback Machine can sometimes reveal information that is no longer publicly accessible, such as contact details, addresses, or financial information.


  1. Identify the Target Website:

    • Assume you are researching the company “ExampleCorp” and its website is www.examplecorp.com.

  2. Access the Wayback Machine:

  3. Enter the Website URL:

    • In the search bar, enter the URL of the company’s website: www.examplecorp.com, and click on “Browse History”.

  4. Explore the Archive Calendar:

    • You will see a timeline and a calendar view showing dates when snapshots of the website were taken. The calendar highlights dates with available snapshots.

  5. Select Historical Snapshots:

    • Click on a year in the timeline and then select a specific date from the calendar to view an archived version of the website from that date. For example, you might choose a snapshot from 2015 to see how the website appeared five years ago.

  6. Review the Archived Website:

    • Analyze the archived pages for information such as:

      • Company Information: Look for changes in company descriptions, leadership, or contact details.

      • Products/Services: Note any changes in the products or services offered.

      • News and Announcements: Check for press releases, news, or updates that may provide insights into the company’s history or business focus.


References:

http://archive.org/web/


Instructor Note

Instructor Notes.


7.1.5 Google Searches

Google is the most popular internet search engine. People use it everyday to find websites about whatever topic they are searching for. Many people do not realize how robust the searching algorithms are and how they can be used to find sensitive information that can be very valuable when performing passive reconnaissance.

Here are some common Google hacking techniques:

  • Filetype Search:

    • Syntax: filetype:

    • Example: filetype:pdf site:example.com

    • Purpose: Finds specific file types on a given site.

  • Site-specific Search:

    • Syntax: site:

    • Example: site:example.com

    • Purpose: Limits the search to a specific website.

  • Intitle and Inurl Searches:

    • Syntax: intitle: and inurl:

    • Example: intitle:"index of" inurl:backup

    • Purpose: Searches for specific words in the title or URL.

  • Link Search:

    • Syntax: link:

    • Example: link:example.com

    • Purpose: Finds pages that link to a specified website.

  • Cache Search:

    • Syntax: cache:

    • Example: cache:example.com

    • Purpose: Displays the cached version of a webpage.

  • Related Search:

    • Syntax: related:

    • Example: related:example.com

    • Purpose: Finds websites similar to the specified domain.

  • Wildcard Search:

    • Syntax: *

    • Example: site:example.*

    • Purpose: Uses a wildcard to search across multiple top-level domains.

  • Combining Operators:

    • Syntax: OR, - (exclude), + (include)

    • Example: site:example.com OR site:example.net -inurl:blog

    • Purpose: Combines operators to refine search results.

  • Specific File Search:

    • Syntax: ext:

    • Example: ext:sql

    • Purpose: Finds specific file types.


References:

Instructor Note

Instructor Notes.


7.1.5.1 Identifying sub-domains with Google searches

*ccboe.net -site:*.ccboe.net


References:

Instructor Note

Ask the students to identify answers to the questions below:

What sub-domains have been found?

Were there any email addresses found?


7.1.5.2 Identifying technologies with Google searches

site:*.ccboe.net "Powered by"

Many technologies like WordPress (for content management) will tend to have "Powered by" in the page footer

Job site listings, Linkedin, and other methods may also help find technologies.


References:


Instructor Note

Instructor Notes.


7.1.6 SHODAN

Shodan

dig2

Shodan searches can reveal clues about technologies that are exposed with simple searches such as cam, phone, printer, Cisco. It is also useful for exposing remote access services, improperly configured services such as SMB, and network infrastructure.

Once an item of interest is selected, you can obtain copious amounts of information such as open services, banners, location, and applicable CVE vulnerabilities.


References:


Instructor Note

Go to the website below and walk-through an example with the students:


7.1.7 Passive OS Fingerprinting (p0f)

Passive OS Fingerprinter (p0f) is a tool which allows the passive scanning of network traffic. Passive OS fingerprinting focuses on uniqueness in IP and TCP implementations to discover which OS sent the traffic. Specifically, p0f looks at the initial TTL, the fragmentation flag, the default packet length of an IP header, the Windows size, and TCP options in TCP SYN and SYN/ACK packets.


p0f.fp (p0f signature file)
Whenever p0f fingerprints traffic it reads from the "p0f.fp" file to identify the operating system and other details.


p0f Signature Database

/etc/p0f/p0f.fp


References:


Instructor Note

Explore the p0f file with the students to explain the way in which the signatures work.


7.1.7.1 Module Specifications

Formatted as follows: [module: direction]

Table 1. Module Specifications
Name Description

module

name of the fingerprinting module (tcp, http, etc.)

direction

direction of the traffic, 'request' from client to server or 'response' for server to client
For the TCP module, 'client' matches initial SYN, and 'server' matches SYN+ACK


Signature Groups

A signature must be preceded by a 'label' describing the fingerprinted information.

label = type:class:name:flavor
Table 2. Signature Groups
Name Description

type

typically an 's' for specific signatures and 'g' for more generic ones.

class

this provides the distinction between OS-identifying signatures (win, unix, cisco, etc.), if a '!' is indicated, that corresponds to more application-related signatures (NMap, Apache, Mozilla, etc.)

name

human-readable short name for what the fingerprint actually identifies (Linux, MacOS, Internet Explorer, Mozilla)

flavor

This is for any further information that needs to be appended to the label, such as "Xmas Scan" for NMap or version numbers for Linux "2.x"


MTU Signatures

Table 3. MTU Signatures
Name Description

label = Ethernet

self explanatory

sig = 1500

MTU size specification


TCP Signatures

sig = ver:ittl:olen:mss:wsize,scale:olayout:quirks:pclass
Table 4. TCP Signatures
Name Description

ver

IP version field. It is 4,6, or * if the version is unimportant to the signature

ittl

initial TTL of the IP packet

olen

IP options length. It is usually 0 for IPv4 and always 0 for IPv6

mss

maximum segment size (mss) that is specified in the TCP options. The * is used to designate that the mss varies

wsize

Windows’ size of the TCP segment. This is expressed as a fixed number, a multiple of the mss, or of the MTU. A rare but possible value is *

scale

is the Window scale (ws) value found in TCP options. If the ws option is not found, this value is 0

olayout

this field represents the TCP option types in the order they appear in the packet, separated by commas. When generating a signature for comparison with the database, this field should be the first that is generated. Eight possible options are:
Table 5. Olayout Options (continued from above)
Name Description

eol+n

explicit end of options followed by n bytes of padding

nop

No Operation (no-op) option

mss

maximum segment size option

ws

Window scaling option

sok

selective ACK permitted option

sack

selective ACK (rarely ever seen)

ts

timestamp option

?n

unknown option ID

quirks

properties observed in the IP or TCP headers. Two common quirks are df for the don’t-fragment flag being set and id+ for when the DF flag is set and the IP identification field is not zero.

pclass

is the payload size of the packet. This is almost always 0, because there is no payload in the three-way handshake.


HTTP signatures

p0f can also determine http signatures based on user agent strings and other information contained within a packet.

sig = ver:horder:habsent:expsw
Table 6. HTTP Signatures

Name

Description

ver

0, for HTTP/1.0, 1 for HTTP/1.1, or * for any

horder

ordered list of headers that should appear in matching traffic.

habsent

list of headers that must not appear in the matching traffic. Useful for noting the absence of standard headers such as "host"

expsw

expected substrings in the 'user-agent' or 'server' field. This is used to detect dishonest software.


References:

p0f Man Page

NullByte: Conduct Passive OS Fingerprinting with P0f


Instructor Note

Demonstrate p0f to the students using the following syntax:


7.1.8 Social Tactics

Social Tactics is a broad term that governs "people manipulation". This is a practice employed in most marketing today. Its studies human behavior and reactions that many may (or may not) be aware that they are doing. Similar strategies can be used to manipulate an individual into taking certain actions that they may not normally do. Social tactics can be broken down into separate venues which we will discuss individually.


References:


Instructor Note

Instructor Notes.


7.1.8.1 Social Engineering

Social Engineering - hacking the person. Typically involves human-to-human interactions. Can be riskier because you may have to expose your identity.

  • Friendliness/Liking - Using flattery and friendliness to get what you want. People are easily persuaded by other people that they like. People were more likely to buy if they liked the person selling it to them. Some of the many biases favoring more attractive people are discussed.

  • Impersonation/Authority - Pretending or pretexting to be another person with the goal of gaining access physically to a system or building. Several impersonation roles fall under the category of someone with authority. People will tend to obey authority figures, even if they are asked to perform objectionable acts.

  • Conformity/Social Proof - Tendency to see an action as appropriate when others are doing it. People will do things that they see other people are doing.

  • Decoying/mental buffer-overflow - People are limited in what we can focus our attention on at any moment. Exploit this limitation by distractions to conceal what they are truly seeking.

  • Diffusion of responsibility - When individuals believe that many others are present or have done a similar act, they as individuals do not bear the full burned of responsibility. It alleviates the stress on the employee and makes it easier for them to comply. "Don’t worry, I will call the Police so you don’t need to worry about it."

  • Reverse Social Engineering - Complex questions can yield data. The attacker appears to be in a position of authority. Employees will ask for information.

    • Components: Sabotage, Advertising, and Assisting. You can break someone’s computer while they are out then show up while they are there and pretend to be tech support and ask " I heard someone’s computer was not working".

    • Questions: Language structure that forces the execution of instructions. A person can ask seemingly random questions that may not seem like much but they can be fishing for valuable information.

    • Job Interview: post a really attractive job position and ensure the link is sent through the target company. If any respond to the ad you can set up an interview to ask questions about setting up security in a network and people tend to divulge details about their own network.

  • Commitment and consistency – If people commit, orally or in writing, to an idea or goal, they are more likely to honor that commitment because of establishing that idea or goal as being congruent with their self-image. Even if the original incentive or motivation is removed after they have already agreed, they will continue to honor the agreement.

  • Reciprocity/Quid pro quo - Reciprocity is an expectation that you will treat others the way they treat you. Reciprocity is based on a universal understanding that people give back to others who have given first.

  • Scarcity/Urgency - Perceived scarcity of an item or time will generate demand.

  • Sympathy - People want to help others who are in desperate need. Playing the victim in desperate need, crying baby, etc. Sharing of unhappiness or suffering. Implies concern, or a wish to alleviate negative feelings others are experiencing.

  • Guilt - Feeling of obligation for not pleasing, not helping, or not placating another. Acceptance of responsibility for someone else’s misfortune or problem because it is bothersome to see that someone suffers.

  • Equivocation - An equivocal statement or question starts out sounding reasonable and gets the target to agree to certain ideas or requests by deliberately attempting to create uncertainty or ambiguity. After that, the meaning of key terms is changed, thus causing the victim to agree to things they would have never accepted at the beginning.

  • Ignorance - Pretending to be uninformed to manipulate a victim to give you information.

  • Affiliation - Name dropping to establish credibility. Reduces the target’s suspicion of the attacker’s motives.

  • Honeytrap - Practice with the use of romantic or sexual relationships for a particular gain.


References:

https://faculty.nps.edu/ncrowe/oldstudents/laribeethesis.htm

https://en.wikipedia.org/wiki/Social_engineering_%28security%29


Instructor Note

Instructor Notes.


7.1.8.2 Technical based

Technical based - utilizes technical means to perform manipulation on a person without needing human-to-human interaction. These can include the use of phones, cell phones, computers, and social media. Less risk because you do not typically expose yourself.

  • phishing - Phisher sends an e-mail that appears to come from a legitimate business—a bank, or credit card company—requesting "verification" of information and warning of some dire consequence if it is not provided. The e-mail usually contains a link to a fraudulent web page that seems legitimate—with company logos and content—and has a form requesting everything from a home address to an ATM card’s PIN or a credit card number.

  • spear phishing - Although similar to "phishing", spear phishing is a technique that fraudulently obtains private information by sending highly customized emails to few end users. It is the main difference between phishing attacks because phishing campaigns focus on sending out high volumes of generalized emails with the expectation that only a few people will respond.

  • whaling - similar to spear phishing except the target is a VIP.

  • vishing - Using a telephone system to gain access to private personal and financial information from the public.

  • smishing - The act of using SMS text messaging to lure victims into a specific course of action. Like Phishing it can be clicking on a malicious link or divulging information

  • pharming - Attack intended to redirect a website’s traffic to another (fake) site. Pharming can be conducted either by changing the hosts file on a victim’s computer or by exploitation of a vulnerability in DNS server software. DNS servers are computers responsible for resolving Internet names into their real IP addresses. Compromised DNS servers are sometimes referred to as "poisoned". Pharming requires unprotected access to target a computer, such as altering a customer’s home computer, rather than a corporate business server.

  • Malvertising - The use of online advertising to spread malware. It typically involves injecting malicious or malware-laden advertisements into legitimate online advertising networks and webpages. Online advertisements provide a solid platform for spreading malware because significant effort is put into them in order to attract users and sell or advertise the product. Because advertising content can be inserted into high-profile and reputable websites, malvertising provides malefactors an opportunity to push their attacks to web users who might not otherwise see the ads, due to firewalls, more safety precautions, or the like. Malvertising is "attractive to attackers because they 'can be easily spread across a large number of legitimate websites without directly compromising those websites'."

  • Watering Hole - Water holing is a targeted social engineering strategy that capitalizes on the trust users have in websites they regularly visit. The victim feels safe to do things they would not do in a different situation. A wary person might, for example, purposefully avoid clicking a link in an unsolicited email, but the same person would not hesitate to follow a link on a website they often visit. So, the attacker prepares a trap for the unwary prey at a favored watering hole. This strategy has been successfully used to gain access to some (supposedly) very secure systems.

  • Device Lean Behind (Road Apple) - The hacker leaves a USB drive, CD-RW, phone, or other storage devices around an office and writes a tempting label on it, like salary information or a famous musician (if it’s a CD). Oftentimes, if someone finds a USB drive, they’ll just start to use it on their own.

  • Evil Troll - Intentional trolling of social media to antagonize and bait others into conflict. In doing so, the troll may be able to manipulate the victim into revealing sensitive or secret information out of anger or to prove a point.

  • Rogue Security (Scareware) - A form of malware which impersonates a fake or simulated anti-spyware or security scanner. It tricks you into believing you are getting protection, when in fact you are infecting your network with malware and the social engineer is stealing your data.

  • Bluetooth

    • Bluejacking. This is the practice of sending unsolicited messages to nearby Bluetooth devices. Bluejacking messages are typically text, but can also be images or sounds. Bluejacking is relatively harmless, but does cause some confusion when users start receiving messages.

    • Bluesnarfing. Any unauthorized access to or theft of information from a Bluetooth connection is bluesnarfing. A bluesnarfing attack can access information, such as email, contact lists, calendars, and text messages. Attackers use tools such as hcitool and obexftp.

    • Bluebugging. Bluebugging attacks allow an attacker to take over a mobile phone. Attackers can listen in on phone conversations, enable call forwarding, send messages, and more.

    • Car whisperer. The attack takes advantage of a common flaw in Bluetooth vehicle implementation wherein certain car manufacturers use the same 1234 or 0000 passkeys for authentication and encryption. Hackers can use a laptop and a Bluetooth antenna to connect and listen in on hands-free conversations or talk directly to the people in the car. Secure your car’s audio, Bluetooth headset, and entertainment system by changing the manufacturer’s PIN code.

    • Location tracking. A Bluetooth attack used for locating and tracking devices. Those usually prone to this attack are fitness enthusiasts because their fitness wearables are always connected to their Bluetooth.

    • BlueBorne. To perform a BlueBorne attack, hackers need to infect your device with malware. That will allow an attacker to take control of the device. What makes things even worse is that, once your device is infected, it can infect other devices it connects to. If your device’s software is outdated and doesn’t use a VPN, it is vulnerable to BlueBorne attacks.


References:


Instructor Note

Instructor Notes.


7.1.8.3 Other Types

Other types - These do not typically involve using technical means or human-to-human interaction.

  • Shoulder Surfing - looking over the victim’s shoulders to collect information.

  • Eavesdropping - It is the process of intercepting unauthorized communication to gather information

  • Dumpster Diving - looking for treasure in someone else’s trash.

  • Tailgating (piggybacking) - When an unauthorized person physically follows an employee into a restricted corporate area or system.

  • Baiting - offering something enticing to an end user in exchange for private data. The “bait” comes in many forms, both digital – such as a music or movie download, and physical – such as a branded flash drive labeled “Executive Salary Summary Q3 2017” that is left out on a desk for someone to find. Once the bait is taken, malicious software is delivered directly into the victim’s computer.

  • War Driving/Chalking - identifying open Wi-Fi hotspots.


References:

Development of Methodical Social engineering Taxonomy Project

Cialdini’s 6 Principles of Persuasion Science


Instructor Note

Instructor Notes.


7.2 Describe Methods Used for Active External Discovery


800


Active external discovery involves actively identifying and probing the external-facing assets, systems, and vulnerabilities of an organization or network from an external viewpoint. This is a key component of the reconnaissance phase in cybersecurity assessments, penetration testing, and ethical hacking. In contrast to passive reconnaissance, where information is collected without direct interaction with the target, active external discovery entails the deployment of probes and requests to collect information and pinpoint potential weaknesses.


References:


Instructor Note

Instructor Notes.


7.2.1 Network Scanning and Banner Grabbing

Network scanning is obviously a critical part of reconnaissance, as it allows you to take a look into the hardware structure and software capabilities of a target. One of the main goals is to discern the vulnerabilities of your target, whether it be an adversary or your own organization. Scanning can be approached in several different manners, but here we will focus on it categorically. The biggest difference in this stage compared to passive is that we will now send packets to our target. This greatly increases the chance of discovery.


References:


Instructor Note

Instructor Notes.


7.2.1.1 Scanning Nature

  • Active - this method aims to provide a comprehensive report of possible open or closed ports at the time of the scan. Active scanning typically performs very fast, and can contain options to vary that speed. However, it is flawed when attempting to detect ports that are filtered by firewalls. A well-known disadvantage of active scanning is that it is very intrusive. Active probes typically solicit a response that would not have been sent otherwise. This traffic is more likely to be detected and logged by the host. In this methodology, packets (whether legal or illegal combinations) will be sent to a target, hence "active". The "stealth" strategies discussed later are still considered active by this definition. in this section, we will focus on active scanning.

  • Passive - identifies network services by observing traffic generated by servers and hosts as it passes an observation point. Distinctively, passive scanning has the advantage of being non-intrusive. In fact, it generally cannot be detected without in-depth and purposeful investigation. Due to the obscure nature of passive scanning, it can run long-term to better detect active services running on transient hosts such as machines that are frequently powered off or hosts temporarily disconnected from the network. Passive scanning can also detect services that active scanning may miss due to firewall configurations. In this methodology, the service acts more as a sniffer, and no "hard" packet is sent out.


References:


Instructor Note

Instructor Notes.


7.2.1.2 Scanning Strategy

  • Remote to Local - refers to a remote host, outside the boundary of a specific network, performing some sort of scan on hosts internal to an enterprise network. This is one of the most commonly used pen-testing or attack methods. It is likely to come from unknown external adversaries. This form of scanning is risky and can put defenders on alert. To avoid this you can try methods of scanning to make it not look like a scan. This can be done by scanning random ports over random amounts of time. You can also source the scans from different IP addresses.

  • Local to Remote - occurs when a host, within the administrative control of an enterprise network, scans systems outside the network boundary. This strategy may cause serious legal issues against an enterprise network without the appropriate permissions since its infrastructure could be used for malicious purposes against Internet systems. This can be ideal for offense. Imagine having a persistance on a 3rd party target that your primary target does business with and perform scans from this 3rd party.

  • Local to Local - refers to a host that scans systems within the boundaries of an enterprise in which it resides. Local to local scanning activity can occur within or between network subnets and is normally employed by network/security admins per policy. This is common when attackers are on the network and are trying to discover other hosts and perform lateral movement.

  • Remote to Remote - does not depend on certain boundaries. It mainly refers to worldwide scanning campaigns. Rather than focusing on a specific network as a target, it aims at probing and exploiting the Internet’s services vices. This strategy is often distributed, possesses sophisticated stealth capabilities, and is typically highly coordinated.


References:


Instructor Note

Instructor Notes.


7.2.1.3 Scanning Approach

Aim

  • Wide Target Scanning:

    • Scope: Wide target scanning involves scanning a broad range of IP addresses or a large network segment.

    • Purpose: The primary goal of wide target scanning is to gather information about a large number of systems within a network or across the internet.

    • Approach: Wide target scanning typically involves using scanning tools like Nmap, Masscan, or Shodan to sweep through a wide range of IP addresses, identifying active hosts, open ports, and potentially vulnerable services.

    • Advantages:

      • Provides a comprehensive overview of the network landscape.

      • Helps identify potential entry points and weak spots across a large network.

    • Challenges:

      • Generates a large volume of data that may require extensive analysis.

      • May result in network congestion or trigger security alerts if performed without proper authorization.

  • Target-Specific Scanning:

    • Scope: Target-specific scanning focuses on a specific set of IP addresses or a particular subset of systems within a network.

    • Purpose: The goal of target-specific scanning is to gather detailed information about specific systems or assets of interest.

    • Approach: Target-specific scanning involves selecting specific IP addresses or systems based on predefined criteria, such as criticality, importance, or suspicion of vulnerability. The scanning is tailored to gather detailed information relevant to the selected targets.

    • Advantages:

      • Allows for a more focused and efficient use of resources.

      • Provides in-depth information about specific systems or assets of interest.

    • Challenges:

      • Requires prior knowledge or intelligence about the target to select appropriate systems for scanning.

      • May overlook potential vulnerabilities or entry points in other parts of the network.


Method

  • Single Source Scan.

    • A single source scan is conducted from one centralized scanning system or node. This system is responsible for sending out all scanning requests and collecting results.

    • Characteristics:

      • Centralized Execution: All scanning activities are performed by one machine, which means the scanning software runs from a single point.

      • Simplicity: Easier to set up and manage since it involves only one system.

      • Resource Constraints: Limited by the capacity and performance of the single scanning system. High traffic or complex scans may impact performance or result in incomplete scans.

      • Network Impact: Can generate significant traffic from one source, potentially causing network congestion or performance issues.

      • Scalability: Less scalable compared to distributed scanning; may not be suitable for very large networks or environments with high complexity.

      • Detection: May be less effective at detecting distributed or segmented vulnerabilities since it scans from a single vantage point.

      • Risk: Scanning traffic originates from a single IP address, which can be more easily detected and flagged by intrusion detection systems (IDS) or intrusion prevention systems (IPS).

Vertical scan

Consists of a port scan of some (or all ports) on a single target.

verticalscan

Horizontal scan

Scan a single (or set) port(s) on a range of targets.

horizontalscan1

Strobe scan

Scan a predefined subset of ports on a range of targets.

horizontalscan2

Block scan

Scan all (or a range) ports on a range of targets.

horizontalscan3


  • Distributed Scan:

    • A distributed scan uses multiple scanning systems or nodes to perform scanning activities. These systems work together to cover larger or more complex networks.

    • Reduces the scanning footprint of any single system and thus decreases the likelihood of being detected.

    • Characteristics:

      • Decentralized Execution: Scanning is performed by multiple systems, each potentially covering different segments of the network.

      • Complexity: More complex to set up and manage due to the coordination between multiple scanning systems.

      • Resource Utilization: Can leverage the resources of multiple systems, improving performance and allowing for more extensive or intensive scanning.

      • Network Impact: Distributes traffic across multiple sources, reducing the likelihood of congestion or performance degradation on any single part of the network.

      • Scalability: Highly scalable; can efficiently handle large, distributed, or complex networks.

      • Detection: Better at identifying vulnerabilities in segmented or complex network environments due to the ability to scan from multiple points.

      • Risk: Scanning traffic is spread across multiple IP addresses, making it more challenging for the target network to detect and block the scanning activity as a whole.

1. Each system performs a thorough Vertical scan across a determined range of target hosts.

distributedscan1

2. Each system is designated specific ports to scan across all target hosts.

distributedscan2


References:


Instructor Note

Instructor Notes.


7.2.1.4 Service Discovery (Port Scanning)

Service Discovery sends TCP or UDP packets to hosts on specific ports. This method queries which hosts are up and which sockets are bound. Because it is most likely that multiple packets are sent to multiple hosts, these techniques are very noticeable on the network unless a large amount of time (low and slow) is taken while completing these scans. For purposes intended to avoid detection, "stealth scans" can be employed. These techniques attempt to avoid filtering devices by using alternative sets of flag combinations to appear as legitimate traffic.

The most common methods of port scanning are SYN scans and TCP Full Connect Scans, with the first considered to be "stealth". Other types of "stealth" scans will be explored later in this section.


References:


Instructor Note

Instructor Notes.


7.2.2 PING

Active External Network Reconnaissance: Scans with FPING or PING

Broadcast Ping

A broadcast ping sends an ICMP echo request to the network broadcast address. Send one ICMP packet that every host receives and all active hosts should respond. Most systems no longer respond to a broadcast ping.


Using ping and ping sweep

A Ping or ping sweep sends an ICMP echo request (icmp type 8) to one or many usable address on a network. It waits to receive a ICMP echo repy (icmp type 0) from active devices. If used, there should be a delay between pings, and hosts pinged should not be sequential.

This is effective if there are no firewalls, but it is very noisy. It is common for firewalls to block ICMP echo requests/replys. If this is the case, then using only ping for reconnaissance will give actors conducting the recon false information thinking there are no other active hosts on the network. Many modern OS’s like Windows 7 drop an ICMP Echo Request by default for security reasons.

A ping sweep in IPv6 is infeasible because there are too many addresses in a typical /64 network.

ping [options] destination

Options:

  • -c count: Specify the number of packets to send (e.g., ping -c 4 will send four packets).

  • -i interval: Specify the interval between packets in seconds.

  • -t timeout: Specify the maximum time to wait for a response.

  • -s packetsize: Specify the size of the data portion of the packet.

  • -q: Quiet output. Displays only summary information at the end.

  • -W timeout: Similar to -t, this option specifies the timeout in seconds but is supported on some systems instead of -t.

  • -f: Flood ping. Sends a large number of packets rapidly for testing network performance.

  • -v: Verbose output. Displays detailed information about each packet.

  • -p: specify a pattern (in hex) to be sent in the ICMP echo request packets.

Ping sweep

-c (--count count) - Stop after sending (and receiving) count.

for i in {1..254}; do (ping -c 1 192.168.65.$i | grep "bytes from" &) ; done


Using FPING:

-g (--generate) addr/mask - Generate a target list from a supplied IP netmask, or a starting and ending IP.
-a (--alive) - Show systems that are alive.

fping -g -a 10.1.0.0/24


Using NMAP:

-sn: Ping Scan - disable port scan

nmap –sn 10.0.0.0/24 (was -sP which is now deprecated)



References:

Fping Man Page

NMAP Man Page

Ping Man Page


Instructor Note

Instructor Notes.


7.2.3 NMAP

Active External Network Reconnaissance: Scans with NMAP

NMAP (Network Mapper) is a popular open source tool for network discovery, exploration and security auditing. NMAP is a command line tool but has a Graphical User Interface (GUI) version call ZENMAP that comes installed when NMAP is installed.

NMAP.org

The default scanning method depends on whether the scan is executed as a user or root. When conducted as a user, the default scan employs a TCP full connect (-sT) as creating RAW SOCKETS, required for other scans, necessitates permissions that a user typically lacks. On the other hand, when executed as a root user, the default scan type is a SYN Scan (-sS). Regardless of the chosen scan method, if specific ports are not designated, NMAP will automatically scan the 1000 most commonly used TCP or UDP ports.

  • User Default: TCP Full Connect Scan (-sT)

  • Root Default: TCP SYN Scan (-sS)

  • Default Ports scanned: 1000 most commonly used TCP or UDP ports.

    nmap -v -oG - | grep "Ports scanned"

  • This list comes from the /usr/share/nmap/nmap-services file based on the frequency of detection.

    sort -r -k3 /usr/share/nmap/nmap-services | less
grep /tcp /usr/share/nmap/nmap-services | sort -r -k3 | less
grep /udp /usr/share/nmap/nmap-services | sort -r -k3 | less


References:

Nmap Reference Guide

Nmap Man Page

https://nmap.org/book/nmap-services.html


Instructor Note

Instructor Notes.


7.2.3.1 NMAP Port States

  • When NMAP starts its port discovery the result can be one of six states: open, closed, filtered, unfiltered, open|filtered, or closed|filtered.

    • The six port states recognized by Nmap:

      • open - An application is actively accepting TCP connections, UDP datagrams or SCTP associations on this port. Open TCP ports are determined by receiving a SYN/ACK response while no response is common for UDP open ports. Finding these is often the primary goal of port scanning. Security-minded people know that each open port is an avenue for attack. Attackers and pen-testers want to exploit the open ports, while administrators try to close or protect them with firewalls without thwarting legitimate users. Open ports are also interesting for non-security scans because they show services available for use on the network.

      • closed - A closed port is accessible (it receives and responds to Nmap probe packets), but there is no application listening on it. This is typically determined by receiving a RST flag on TCP ports or an ICMP Destination unreachable, Destination port unreachable (Type 3 Code 3) on a UDP port. They can be helpful in showing that a host is up on an IP address (host discovery, or ping scanning), and as part of OS detection. Because closed ports are reachable, it may be worth scanning later in case some open up. Administrators may want to consider blocking such ports with a firewall. Then they would appear in the filtered state, discussed next.

      • filtered - Nmap cannot determine whether the port is open because packet filtering prevents its probes from reaching the port. If a RST or ICMP message was not received from the probed port then it can be assumed that the port may be filtering these probes. The filtering could be from a dedicated firewall device, router rules, or host-based firewall software. These ports frustrate attackers because they provide so little information. Sometimes they respond with ICMP error messages such as type 3 code 13 (destination unreachable: communication administratively prohibited), but filters that simply drop probes without responding are far more common. This forces Nmap to retry several times just in case the probe was dropped due to network congestion rather than filtering. This slows down the scan dramatically.

      • unfiltered - The unfiltered state means that a port is accessible, but Nmap is unable to determine whether it is open or closed. Only the ACK scan, which is used to map firewall rulesets, classifies ports into this state. Scanning unfiltered ports with other scan types such as Window scan, SYN scan, or FIN scan, may help resolve whether the port is open.

      • open|filtered - Nmap places ports in this state when it is unable to determine whether a port is open or filtered. This occurs for scan types in which open ports give no response. The lack of response could also mean that a packet filter dropped the probe or any response it elicited. So Nmap does not know for sure whether the port is open or being filtered. The UDP, IP protocol, FIN, NULL, and Xmas scans classify ports this way.

      • closed|filtered - This state is used when Nmap is unable to determine whether a port is closed or filtered. It is only used for the IP ID idle scan.


References:

https://nmap.org/book/man-port-scanning-basics.html


Instructor Note

Instructor Notes.


7.2.3.2 NMAP Options

  • TARGET SPECIFICATION:

    Can pass hostnames, IP addresses, networks, etc.
Ex: scanme.nmap.org, microsoft.com/24, 192.168.0.1; 10.0.0-255.1-254
-iL <inputfilename>: Input from list of hosts/networks
-iR <num hosts>: Choose random targets
--exclude <host1[,host2][,host3],...>: Exclude hosts/networks
--excludefile <exclude_file>: Exclude list from file

  • HOST DISCOVERY:

    -sL: List Scan - simply list targets to scan
-sn: Ping Scan - disable port scan
-Pn: Treat all hosts as online -- skip host discovery
-PS/PA/PU/PY[portlist]: TCP SYN/ACK, UDP or SCTP discovery to given ports
-PE/PP/PM: ICMP echo, timestamp, and netmask request discovery probes
-PO[protocol list]: IP Protocol Ping
-n/-R: Never do DNS resolution/Always resolve [default: sometimes]
--dns-servers <serv1[,serv2],...>: Specify custom DNS servers
--system-dns: Use OS's DNS resolver
--traceroute: Trace hop path to each host

  • SCAN TECHNIQUES:

    -sS/sT/sA/sW/sM: TCP SYN/Connect()/ACK/Window/Maimon scans
-sU: UDP Scan
-sN/sF/sX: TCP Null, FIN, and Xmas scans
--scanflags <flags>: Customize TCP scan flags
-sI <zombie host[:probeport]>: Idle scan
-sY/sZ: SCTP INIT/COOKIE-ECHO scans
-sO: IP protocol scan
-b <FTP relay host>: FTP bounce scan

  • PORT SPECIFICATION AND SCAN ORDER:

    -p <port ranges>: Only scan specified ports
  Ex: -p22; -p1-65535; -p U:53,111,137,T:21-25,80,139,8080,S:9
--exclude-ports <port ranges>: Exclude the specified ports from scanning
-F: Fast mode - Scan fewer ports than the default scan
-r: Scan ports sequentially - don't randomize
--top-ports <number>: Scan <number> most common ports
--port-ratio <ratio>: Scan ports more common than <ratio>

  • SERVICE/VERSION DETECTION:

    -sV: Probe open ports to determine service/version info
--version-intensity <level>: Set from 0 (light) to 9 (try all probes)
--version-light: Limit to most likely probes (intensity 2)
--version-all: Try every single probe (intensity 9)
--version-trace: Show detailed version scan activity (for debugging)

  • SCRIPT SCAN:

    -sC: equivalent to --script=default
--script=<Lua scripts>: <Lua scripts> is a comma separated list of
         directories, script-files or script-categories
--script-args=<n1=v1,[n2=v2,...]>: provide arguments to scripts
--script-args-file=filename: provide NSE script args in a file
--script-trace: Show all data sent and received
--script-updatedb: Update the script database.
--script-help=<Lua scripts>: Show help about scripts.
         <Lua scripts> is a comma-separated list of script-files or
         script-categories.

  • OS DETECTION:

    -O: Enable OS detection
--osscan-limit: Limit OS detection to promising targets
--osscan-guess: Guess OS more aggressively

  • TIMING AND PERFORMANCE:

    Options which take <time> are in seconds, or append 'ms' (milliseconds),
's' (seconds), 'm' (minutes), or 'h' (hours) to the value (e.g. 30m).
-T<0-5>: Set timing template (higher is faster)
--min-hostgroup/max-hostgroup <size>: Parallel host scan group sizes
--min-parallelism/max-parallelism <numprobes>: Probe parallelization
--min-rtt-timeout/max-rtt-timeout/initial-rtt-timeout <time>: Specifies
    probe round trip time.
--max-retries <tries>: Caps number of port scan probe retransmissions.
--host-timeout <time>: Give up on target after this long
--scan-delay/--max-scan-delay <time>: Adjust delay between probes
--min-rate <number>: Send packets no slower than <number> per second
--max-rate <number>: Send packets no faster than <number> per second

  • FIREWALL/IDS EVASION AND SPOOFING:

    -f; --mtu <val>: fragment packets (optionally w/given MTU)
-D <decoy1,decoy2[,ME],...>: Cloak a scan with decoys
-S <IP_Address>: Spoof source address
-e <iface>: Use specified interface
-g/--source-port <portnum>: Use given port number
--proxies <url1,[url2],...>: Relay connections through HTTP/SOCKS4 proxies
--data <hex string>: Append a custom payload to sent packets
--data-string <string>: Append a custom ASCII string to sent packets
--data-length <num>: Append random data to sent packets
--ip-options <options>: Send packets with specified ip options
--ttl <val>: Set IP time-to-live field
--spoof-mac <mac address/prefix/vendor name>: Spoof your MAC address
--badsum: Send packets with a bogus TCP/UDP/SCTP checksum

  • OUTPUT:

    -oN/-oX/-oS/-oG <file>: Output scan in normal, XML, s|<rIpt kIddi3,
   and Grepable format, respectively, to the given filename.
-oA <basename>: Output in the three major formats at once
-v: Increase verbosity level (use -vv or more for greater effect)
-d: Increase debugging level (use -dd or more for greater effect)
--reason: Display the reason a port is in a particular state
--open: Only show open (or possibly open) ports
--packet-trace: Show all packets sent and received
--iflist: Print host interfaces and routes (for debugging)
--append-output: Append to rather than clobber specified output files
--resume <filename>: Resume an aborted scan
--noninteractive: Disable runtime interactions via keyboard
--stylesheet <path/URL>: XSL stylesheet to transform XML output to HTML
--webxml: Reference stylesheet from Nmap.Org for more portable XML
--no-stylesheet: Prevent associating of XSL stylesheet w/XML output

  • MISC:

    -6: Enable IPv6 scanning
-A: Enable OS detection, version detection, script scanning, and traceroute
--datadir <dirname>: Specify custom Nmap data file location
--send-eth/--send-ip: Send using raw ethernet frames or IP packets
--privileged: Assume that the user is fully privileged
--unprivileged: Assume the user lacks raw socket privileges
-V: Print version number
-h: Print this help summary page.


References:

https://nmap.org/book/man-briefoptions.html

https://nmap.org/book/man-port-specification.html


Instructor Note

Instructor Notes.


7.2.3.3 NMAP Scan Types


References:

https://nmap.org/book/man-port-scanning-techniques.html


Instructor Note

Instructor Notes.


7.2.3.3.1 SYN Scan

SYN scan sends only one TCP packet with the SYN flag set to each destination port and waits for a SYN/ACK or RST. This is also known as a Stealth Scan. This method reports if there is an application listening on the target port and does not register on the host system, because no ACK is sent to the target. This method does not retrieve any information about the service.

nmap –sS 172.16.82.106
hping3 172.16.82.106 -S -V -p 443

  • TCP Three-Way Handshake:

    • In a typical TCP connection, a three-way handshake occurs:

      • The scanning tool (Nmap) sends a SYN (synchronize) packet to the target port.

      • If the port is open and accepting connections, the target system responds with a SYN-ACK (synchronize-acknowledge) packet.

      • Finally, the scanning tool sends an ACK (acknowledge) packet to complete the connection setup.

  • Packet Generation:

    • In a TCP SYN scan, Nmap sends SYN packets to the target ports to initiate a connection.

    • Unlike a TCP Full Connect scan, it does not complete the three-way handshake by sending an ACK packet after receiving a SYN-ACK response.

  • Target Response:

    • If the target port responds with a SYN-ACK packet, indicating that the port is open and accepting connections, Nmap does not complete the connection setup.

    • If the port is closed or filtered (firewalled), the target system typically responds with an RST (reset) packet to indicate that the connection cannot be established.

  • Interpreting Results:

    • If Nmap receives a SYN-ACK packet in response to the SYN packet, it marks the port as open.

    • If Nmap receives an RST packet in response to the SYN packet, it marks the port as closed.

    • If Nmap does not receive any response, it typically indicates that the port is filtered (firewalled).

  • Use Cases:

    • TCP SYN scans are fast and stealthy, making them suitable for scanning large numbers of ports quickly.

    • They are commonly used for reconnaissance to identify open ports and potentially vulnerable services on target systems.

    • TCP SYN scans are less likely to be logged and detected compared to TCP Full Connect scans because they do not complete the TCP connection setup.


SYN scan is the default scan type when running as the root user.


References:


Instructor Note

Instructor Notes.


7.2.3.3.2 Full Connect Scan

Full-Connect scan establishes a complete TCP three-way handshake with a system. The advantage of this method is that a fully functional connection to the target host is made which allows information to be gathered from the listening service (aka banner grabbing). The down side to this method is that the connection is logged on the system being targeted. If done many times, a netstat on that system shows many established connections between the source and target.

nmap –sT –sV 172.16.82.106
(Full TCP connect, service versioning)
nmap –sT 172.16.82.106

  • TCP Three-Way Handshake:

    • In a typical TCP connection, a three-way handshake occurs:

      • The scanning tool (Nmap) sends a SYN (synchronize) packet to the target port.

      • If the port is open and accepting connections, the target system responds with a SYN-ACK (synchronize-acknowledge) packet.

      • Finally, the scanning tool sends an ACK (acknowledge) packet to complete the connection setup.

  • Packet Generation:

    • In a TCP Full Connect scan, Nmap sends SYN packets to the target ports to initiate a connection.

    • If the target port responds with a SYN-ACK packet, indicating that the port is open and accepting connections, Nmap proceeds to complete the connection by sending an ACK packet.

    • If the port is closed or filtered (firewalled), the target system typically responds with an RST (reset) packet to indicate that the connection cannot be established.

  • Target Response:

    • If the target port responds with a SYN-ACK packet, indicating that the port is open, Nmap completes the TCP connection by sending an ACK packet.

    • If the port is closed or filtered, the target system typically responds with an RST packet, indicating that the connection cannot be established.

    • Nmap analyzes the responses to determine the status of each scanned port.

  • Interpreting Results:

    • If Nmap receives a SYN-ACK packet followed by an ACK packet, it marks the port as open.

    • If Nmap receives an RST packet in response to the SYN packet, it marks the port as closed.

    • If Nmap does not receive any response, it typically indicates that the port is filtered (firewalled).

  • Use Cases:

    • TCP Full Connect scans are reliable and thorough, providing accurate information about the status of each scanned port.

    • They are useful for reconnaissance to identify open ports and potentially vulnerable services on target systems.

    • TCP Full Connect scans are more likely to be logged and detected compared to other scan types (e.g., SYN scans, NULL scans), but they provide more detailed information about the target system’s TCP/IP stack behavior.


TCP Full Connect scan, also known as a TCP Connect scan, is the default scan type used when running as a non-root user. This scan requires sudo to run when not a root user.


References:


Instructor Note

Instructor Notes.


7.2.3.3.3 Null Scan

A null scan has no flags set and a sequence number of 0. All legitimate traffic has flags set, causing any null scan traffic to stand out if viewed. This scan is useful to penetrate firewalls and routers set to filter certain flags out since it uses no flags. Open and filtered ports should have no response, filtered ports may also send an ICMP unreachable message, and closed ports should send a RST packet.

nmap -sN 172.16.82.106
hping3 -c 1 -V -p 80 -s 5050 -Y 172.16.82.106

  • TCP Flags:

    • TCP (Transmission Control Protocol) packets contain various flags, including SYN, ACK, FIN, RST, PSH, URG, and SYN-ACK.

    • In a null scan, Nmap sends TCP packets with none of these flags set, making the packet effectively "empty" in terms of TCP flags.

  • Packet Generation:

    • Nmap generates TCP packets with no TCP flags set and sends them to the target system.

    • This essentially means that no specific request or action is being made by the sender, as no flags are set in the TCP header.

  • Target Response:

    • If a port is open and the system receives a null packet, it may respond in various ways depending on its configuration:

      • Some systems may respond with an RST (Reset) packet to indicate that the port is closed.

      • Other systems may simply drop the packet without any response.

      • In some cases, the system may respond with different behavior, which can be indicative of its TCP/IP stack implementation.

  • Interpreting Results:

    • If Nmap receives an RST packet in response to the null packet, it marks the port as closed.

    • If Nmap does not receive any response, it typically indicates that the port is open or filtered (firewalled). However, as with other TCP scans, this can also happen if the target system is configured not to respond to null packets.

  • Stealthiness:

    • Null scans are considered stealthy because they send packets with no TCP flags set, making them less likely to be detected by intrusion detection/prevention systems (IDS/IPS).

    • Some firewalls and security devices may not be configured to detect or block null packets, allowing the scan to proceed undetected.

  • Use Cases:

    • Null scans are used for reconnaissance to identify open ports and potentially vulnerable services on target systems.

    • They can be effective in certain scenarios where other scanning techniques might be detected or blocked.


References:


Instructor Note

Instructor Notes.


7.2.3.3.4 FIN Scan

A fin scan is a packet with just the FIN flag set. The packet tries to close a connection that does not exist as a way to obtain information. Like the null scan it works to go through firewalls and routers, in addition to being considered stealthier due to the illegal flag combination. Open and filtered ports should have no response, filtered ports may also send an ICMP unreachable message, and closed ports should send a RST packet.

nmap -sF 172.16.82.106
hping3 -c 1 -V -p 80 -s 5050 -F 172.16.82.106

  • TCP Flags:

    • TCP (Transmission Control Protocol) packets contain various flags, including SYN, ACK, FIN, RST, and others.

    • The FIN (Finish) flag is used to indicate the end of data transmission in a TCP connection.

  • Packet Generation:

    • In a FIN scan, Nmap generates TCP packets with only the FIN flag set and sends them to the target system.

    • The absence of the SYN flag (used to initiate a connection) in the packet means that no connection is established.

  • Target Response:

    • If a port is open and the system receives a packet with the FIN flag, it should typically respond with an RST (Reset) packet to indicate that the port is closed.

    • If a port is closed, some systems might respond with an RST packet, while others might simply drop the packet without any response.

  • Interpreting Results:

    • If Nmap receives an RST packet in response to the FIN packet, it marks the port as closed.

    • If Nmap does not receive any response, it typically indicates that the port is open or filtered (firewalled). However, it’s important to note that this can also happen if the target system is configured not to respond to FIN packets.

  • Stealthiness:

    • FIN scans are considered stealthy because they don’t complete the TCP handshake, making them less likely to be logged by intrusion detection/prevention systems (IDS/IPS).

    • Some older or poorly configured firewalls and security devices may not detect or block FIN packets, allowing the scan to proceed undetected.

  • Use Cases:

    • FIN scans are often used to perform reconnaissance on target systems while minimizing the chance of detection.

    • They can be useful for identifying open ports and potentially vulnerable services without triggering alerts on monitored networks.


References:


Instructor Note

Instructor Notes.


7.2.3.3.5 XMAS Tree Scan

A christmas tree scan is a packet with varying definitions. From nmap it is defined as a packet with FIN, PSH, and URG flags set, while ISS (IBM Internet Security Systems) defines it as all flags are set. Open and filtered ports should have no response, filtered ports may also send an ICMP unreachable message, and closed ports should send a RST packet.

nmap -sX 172.16.82.106
hping3 -c 1 -V -p 80 -s 5050 -M 0 -UPF 172.16.82.106

  • TCP Flags:

    • TCP (Transmission Control Protocol) packets contain various flags, including FIN, URG, PSH, RST, SYN, and ACK.

    • In an Xmas scan, Nmap sets the FIN (Finish), URG (Urgent), and PSH (Push) flags in the TCP header.

  • Packet Generation:

    • Nmap generates TCP packets with the FIN, URG, and PSH flags set and sends them to the target system.

    • This combination of flags is unusual and may bypass certain firewall or intrusion detection system (IDS) configurations.

  • Target Response:

    • If a port is open and the system receives an Xmas packet, it may respond in various ways depending on its configuration:

      • Some systems may respond with an RST (Reset) packet to indicate that the port is closed.

      • Other systems may simply drop the packet without any response.

      • In some cases, the system may respond with different behavior, which can be indicative of its TCP/IP stack implementation.

  • Interpreting Results:

    • If Nmap receives an RST packet in response to the Xmas packet, it marks the port as closed.

    • If Nmap does not receive any response, it typically indicates that the port is open or filtered (firewalled). However, as with other TCP scans, this can also happen if the target system is configured not to respond to Xmas packets.

  • Stealthiness:

    • Xmas scans are considered stealthy because they send packets with unusual combinations of TCP flags, which may evade detection by some security devices.

    • Some firewalls and IDS/IPS systems may not be configured to detect or block Xmas packets, allowing the scan to proceed undetected.

  • Use Cases:

    • Xmas scans are used for reconnaissance to identify open ports and potentially vulnerable services on target systems.

    • They can be effective in certain scenarios where other scanning techniques might be detected or blocked.


References:


Instructor Note

Instructor Notes.


7.2.3.3.6 UDP Scan

A UDP Scan can be used to find *nix hosts that are blocking TCP and ICMP traffic. Since UDP is a stateless protocol it is often used to get through stateful firewalls. This kind of scan is not very useful for service discovery because UDP is connection-less. UDP is dependent on the application as to how or if there is a response.

 nmap –sU -v 172.16.82.106

  • UDP Basics:

    • UDP is a connectionless protocol, meaning it doesn’t establish a connection before sending data.

    • It sends packets (datagrams) without verifying whether the recipient is available or ready to receive the data.

    • UDP is often used for real-time communication where speed and efficiency are more critical than reliability.

  • UDP Scan Operation:

    • In a UDP scan, the scanning tool sends UDP packets to specific ports on the target system.

    • The scanning tool doesn’t wait for a response. Instead, it sends the packets and moves on to the next port.

    • If a UDP packet is received by the target system on a closed port, the system typically responds with an ICMP port unreachable message.

    • If a UDP packet is received on an open port, the target system may not send any response, as UDP doesn’t require acknowledgment.

    • Therefore, determining whether a UDP port is open or closed can be more challenging compared to TCP ports.

  • Interpreting Results:

    • When analyzing the results of a UDP scan, the absence of a response doesn’t necessarily mean the port is closed. It could be open, but the target system might be configured not to respond to UDP packets.

    • Confirmation of an open UDP port often requires additional techniques, such as application-specific probes or packet sniffing to detect responses from the target system.

    • False positives and false negatives are common in UDP scanning due to the unreliable nature of UDP.

  • Use Cases:

    • UDP scanning is commonly used for discovering services and applications that might be running on non-standard ports or where TCP scanning might not provide accurate results.

    • It’s particularly useful for identifying services like DNS (Domain Name System), SNMP (Simple Network Management Protocol), and DHCP (Dynamic Host Configuration Protocol), which primarily rely on UDP.


References:


Instructor Note

Instructor Notes.


7.2.3.3.7 Idle Scan

An idle scan is a more complex stealth technique that utilizes the previously discussed SYN scan. The scan aims to gather port information using a zombie station on the network where the scanning process appears to have been initiated by the zombie IP address instead of the actual source station who will spoof this address later in the process. This scanning method exploits IP fragmentation identification sequences and implements IP address spoofing.

nmap -sI 172.16.40.10 172.16.82.106

  • Principle of IP ID Sequence Prediction:

    • Some systems increment their IP ID (Identification) field for each packet they send, including packets destined for other hosts.

    • If a system receives packets that it hasn’t initiated (like those from an idle scan), its IP ID sequence can reveal whether the scanned port is open, closed, or filtered.

  • Preparation Phase:

    • The scanning process starts with identifying a suitable "zombie" system that meets specific criteria:

      • It must be idle (not actively communicating with other hosts).

      • It must have predictable IP ID sequence generation behavior.

      • It must be able to reach the target host.

      • The attacker sends crafted SYN packets to the zombie host, making it initiate connections to the target host as part of the idle scan.

  • Idle Scan Execution:

    • The attacker sends SYN packets to the zombie host, requesting connections to the desired target port.

    • The zombie host sends the SYN packets to the target as if they were originated by the zombie.

    • The attacker monitors the changes in the IP ID sequence of packets received from the target.

    • By analyzing the changes in the IP ID sequence, the attacker can infer whether the target port is open, closed, or filtered without directly interacting with the target.

  • Interpreting Results:

    • If the IP ID sequence increases after sending a SYN packet to the target port, it indicates that the port is open.

    • If the IP ID sequence remains the same or changes unpredictably, it suggests that the port is closed or filtered.

    • The attacker correlates the IP ID sequence changes with the SYN packets sent to determine the status of each scanned port.

  • Stealthiness and Anonymity:

    • Idle scans are considered stealthy and hard to detect because they leverage third-party hosts (zombies) to perform the scanning.

    • Since the scans appear to originate from the zombie host, the target system logs show activity from the zombie, not from the attacker.

  • Use Cases:

    • Idle scans are useful when stealth is paramount, such as in penetration testing or ethical hacking scenarios.

    • They can help identify open ports and services on a target system without triggering alarms or raising suspicion.


References:


Instructor Note

Instructor Notes.


7.2.3.3.8 Decoy scan

A decoy scan sends multiple packets to each port with different source addresses. This makes it difficult to detect the source but generates lot of traffic. Using ME in your IP list specifies where it is used in the order, and with larger amounts of IPs can mean that yours will not display.

nmap -D 1.2.3.4,5.6.7.8,ME 172.16.82.106


  • Decoy IP Addresses:

    • In a decoy scan, the attacker specifies multiple IP addresses (decoy hosts) in addition to their own IP address.

    • These decoy IP addresses are chosen to be addresses that are unlikely to be associated with the attacker, such as IPs from other networks or even legitimate hosts on the internet.

  • Packet Generation:

    • Nmap generates TCP SYN packets (or other types of probes) as part of the scan.

    • In addition to sending SYN packets from the attacker’s IP address, Nmap also sends SYN packets from the specified decoy IP addresses.

    • The target system receives these packets and logs them as potential scan attempts.

  • Target Response:

    • When the target system receives SYN packets from multiple IP addresses, it may become confused about the true source of the scan.

    • The target system may log the decoy IP addresses as potential sources of the scan, making it harder to trace the scan back to the real attacker.

  • Interpreting Results:

    • From the perspective of the target system, it appears as if the scan is originating from multiple sources (decoy hosts) rather than just one.

    • This can make it more difficult for the target system to identify the true source of the scan or to distinguish it from legitimate network traffic.

  • Stealthiness:

    • Decoy scans are considered stealthy because they blend the attacker’s activity with legitimate traffic from decoy hosts.

    • By using decoy IP addresses, the attacker can make it harder for intrusion detection systems (IDS) and network administrators to detect and respond to the scan.

  • Use Cases:

    • Decoy scans are often used by attackers to conceal their true identity and evade detection during reconnaissance activities.

    • They can be particularly useful when conducting penetration tests or security assessments where stealth is important.


References:


Instructor Note

Instructor Notes.


7.2.3.3.9 Window Scan

A window scan functions like an ACK scan but uses the windows size of the responses to determine whether it is open or closed. An ACK scan returns most results as filtered and can be fairly inaccurate. By using the window size the scan can better determine if it is open, closed, or filtered. If the window field is non zero it will display as open, a zero window field will display as closed, and either no response or ICMP unreachable will display as filtered.

nmap -sW 172.16.82.106

  • Window Scan Operation:

    • Send Packets: The scanner sends TCP packets to the target ports with a flag that is not part of a standard connection attempt. Analyze Responses: The target system responds, and the scanner examines the TCP window size field in the responses.

      • Open Ports: Typically, an open port will respond with a window size that indicates the port is open and accepting connections.

      • Closed Ports: Closed ports may respond with a different window size or not respond at all, depending on how the target system handles the packet.


References:


Instructor Note

Instructor Notes.


7.2.3.3.10 RPC scan

A RPC scan is looking for services that use RPC (remote Procedure Call). The RPC scan is designed to discover RPC services and their corresponding RPC programs, versions, and sometimes even specific vulnerabilities. This can be useful for network enumeration, identifying exposed RPC services, and assessing security risks.

RPC allows for remote commands to be run on machines and this scan will determine the services and version of the service when run. In updated versions of nmap -sR is aliased to -sV (version scanning) and activates version scanning with the RPC scanning.

nmap -sR 172.16.82.106

  • How It Works

    • Scanning for RPC Services:

      • Send RPC Requests: nmap sends various RPC requests to the target ports that are typically associated with RPC services.

      • Receive Responses: The target system responds with information about the RPC services running, including service names, versions, and available procedures.

    • Enumerate RPC Services:

      • Service Detection: nmap identifies which RPC services are active and collects information about them.

      • Port Mapping: It can identify which ports are being used for RPC services and whether they are accessible.


References:


Instructor Note

Instructor Notes.


7.2.3.3.11 FTP bounce scan

An FTP bounce scan, also known as a proxy scan, is a technique used by Nmap to scan networks indirectly through an FTP server. This method can be useful when direct scanning is blocked or difficult due to network restrictions.

FTP Bounce: An attack technique that takes advantage of the FTP server’s ability to open connections to arbitrary ports on other systems. It utilizes the FTP PORT command to route traffic through the FTP server, potentially bypassing firewalls and other network security measures. The primary use of an FTP Bounce scan is to perform port scanning on target systems that may be behind firewalls or other network defenses. By using the FTP server as a proxy, it can sometimes scan ports that are not directly accessible from the attacker’s network.

nmap -b <name>:<pass>@<ftp_server> <victim>
nmap -v -p 21,22,445,80,443 -b student:password@172.16.40.10 192.168.0.0/24

  • Performing the FTP Bounce Scan

    • Connect to the FTP Server:

      • The attacker first connects to an FTP server. The FTP server must be configured to accept connections from the attacker and should not have restrictions on the PORT command.

    • Send PORT Commands:

      • The attacker sends a series of PORT commands to the FTP server. Each PORT command specifies an arbitrary port on the target system to which the FTP server should connect.

      • For example, if the attacker wants to scan port 80 on a target system, the PORT command would instruct the FTP server to connect to port 80 on the target.

    • FTP Server Connects to Target:

      • The FTP server then attempts to establish a connection from itself to the specified port on the target system. This connection attempt is made on behalf of the attacker.

    • Analyze Responses:

      • Open Port: If the target system accepts the connection, it indicates that the port is open.

      • Closed Port: If the target system rejects the connection, it indicates that the port is closed.

      • Filtered Port: If there is no response, it might indicate that the port is filtered or blocked by a firewall.


References:


Instructor Note

Instructor Notes.


7.2.3.3.12 OS fingerprinting scan

An OS fingerprinting scan uses TCP/IP stack fingerprinting to determine what OS is being used. By sending TCP and UDP packets it gathers information such as window size, TCP option ordering and IP ID sampling. It runs that information against its OS database. If a match is found it provides Vendor, OS, Generation, and device type.

nmap -O 172.16.82.106

  • How it Works:

    • Probe Selection: Nmap sends a series of probes to the target, including TCP SYN, ACK, RST, and ICMP packets, as well as UDP packets. These probes are designed to elicit specific responses from the target’s operating system.

    • Response Analysis: Nmap examines the target’s responses to these probes, looking for patterns and characteristics that are unique to different operating systems. These characteristics can include:

      • TCP/IP stack behavior: How the target handles TCP/IP packets, such as the timing of responses, the use of options, and the handling of errors.

      • Protocol version and features: The specific versions of TCP, UDP, and ICMP supported by the target, as well as any additional features or extensions.

      • Service banner information: The content and format of service banners sent by applications running on the target.

      • ICMP responses: The types of ICMP responses received from the target, such as echo replies, port unreachable messages, or time exceeded messages.

    • Pattern Matching: Nmap compares the observed responses to a database of known operating system signatures. This database contains information about the expected behavior of various operating systems under different probing conditions.

    • Fingerprint Generation: Based on the matching patterns, Nmap generates a fingerprint that represents the likely operating system of the target. This fingerprint can be a simple string, a numerical code, or a more complex data structure.


References:


Instructor Note

Instructor Notes.


7.2.3.3.13 Version scan

A version scan uses open ports and the nmap-service-probes databases to query services to confirm the service running on a port and provide the version of the service running. This allows exploits to be properly chosen for use since different versions and patches are susceptible to different things.

nmap -sV 172.16.82.106

  • How it Works:

    • Port Scanning: Nmap first identifies the open ports on the target system.

    • Service Detection: Once open ports are found, Nmap attempts to determine the type of service running on each port. This is often done by analyzing the service banners sent by the service.

    • Version Identification: For each identified service, Nmap sends specially crafted packets or commands designed to elicit version information. These packets or commands may vary depending on the service.

    • Response Analysis: Nmap examines the responses from the service to extract the version number or other identifying information. This can involve parsing the service banner, analyzing the content of packets, or looking for specific patterns in the responses.

    • Version Database: Nmap compares the extracted version information to a database of known service versions. This database contains information about the vulnerabilities and security implications associated with different versions of each service.


References:


Instructor Note

Instructor Notes.


7.2.3.3.14 Maimon scan

The Maimon scan is named after its discoverer, Uriel Maimon. This technique is exactly the same as NULL, FIN, and Xmas scan, except that the probe is FIN/ACK. It is meant to determine open and closed ports on BSD derived systems. Other systems will generate a RST packet regardless of the port’s state. No response indicates either open or filtered, RST closed, and ICMP unreachable error as filtered.

nmap -sM 172.16.82.106

When sending a FIN/ACK packet to a port, the expected behavior is for the port to reply with a RST (Reset) packet if the FIN/ACK is out of state or if the port is closed. This is because a FIN/ACK is not part of a typical TCP connection sequence and indicates an invalid or unexpected state.

However, if no response is received after sending a FIN/ACK, it might suggest that the target host is running a BSD-derived operating system and the port is actually open. This behavior is characteristic of many BSD-based systems, which tend to drop unsolicited FIN/ACK packets silently on open ports, rather than responding with a RST packet. Therefore, the absence of a RST response can be an indication that the port is open on such systems.


References:


Instructor Note

Instructor Notes.


7.2.3.3.15 ICMP echo discovery probe

The Nmap ICMP Echo Discovery Probe is a network discovery technique used by Nmap to determine whether a host is active and reachable on a network. This method utilizes the ICMP (Internet Control Message Protocol) Echo Request and Echo Reply messages, which are fundamental components of the ICMP protocol used for network diagnostics and troubleshooting.

-PE - ICMP Echo Request (Ping) (ICMP type 8/0) scan to discover whether hosts are up and reachable on a network.

nmap -PE 172.16.82.106/27


References:


Instructor Note

Instructor Notes.


7.2.3.3.16 Timestamp Discovery Probe

The Timestamp Discovery Probe in Nmap uses ICMP Timestamp Requests (ICMP type 13/14) to determine if hosts are up and reachable. This method can sometimes bypass certain network filtering or firewall rules that might block other types of probes.

-PP - Uses ICMP Timestamp Request packets (ICMP type 13/14) for host discovery.

nmap -PP 172.16.82.96/27


References:


Instructor Note

Instructor Notes.


7.2.3.3.17 Netmask Request Discovery Probe

Nmap’s Netmask Request Discovery Probe works by sending a specific type of ICMP packet known as an ICMP Netmask Request to a target IP address. This packet asks the target host to provide its subnet mask, which is a piece of information used to determine the range of IP addresses within a network.

-PM - Uses ICMP address mask request packets (ICMP type 17/18) for host discovery. This method is less common but can sometimes bypass certain firewall rules that block ICMP Echo Requests.

nmap -PM -Pn 172.16.82.106


References:


Instructor Note

Instructor Notes.


7.2.3.3.18 TCP SYN Discovery Ping

A syn/ack discovery ping sends an empty TCP packet with only the SYN flag set. When sent, this scan expects a RST packet if the port is closed or a SYN/ACK if the port is open. By default it uses only port 80 and is designed to work only for privileged users on Unix boxes. The scan automatically uses a workaround if the user is not privileged. Returns improper results

nmap -PS21-50 172.16.82.106


References:


Instructor Note

Instructor Notes.


7.2.3.3.19 TCP ACK Discovery Ping

A TCP discovery ping works like the SYN Discovery ping but sets the ACK flag instead of the SYN flag. Both are offered to better allow a user access around or through a firewall. Only works on the same network

nmap -PA21-50 172.16.82.106
hping3 -c 1 -V -p 80 -s 5050 -A 172.16.82.106 (TCP ACK Scan)


References:


Instructor Note

Instructor Notes.


7.2.3.3.20 UDP Discovery Ping

A UDP Discovery scan uses the same idea as both the SYN Discovery ping and the ACK Discovery ping. The difference here is that instead of a TCP packet it uses a UDP packet. Packets are empty except for a few ports (53 and 161). ICMP unreachable messages indicate a closed port, any other ICMP message or no response indicates a down/unreachable host, open ports also will drop responses if there is no payload. The lack of true responses makes this an unreliable scan, but it is able to get around firewalls designed for TCP. Does not return a proper response

nmap -PU21-50 172.16.82.106


References:


Instructor Note

Instructor Notes.


7.2.3.3.21 SCTP INIT Scan

A SCTP INIT scan has characteristics of both TCP and UDP with other features as well. This is the SCTP version of the TCP SYN scan and is able to get through most firewalls. It is considered fairly stealthy and gives reliable open, closed, and filtered results. An INIT-ACK shows as open, no response shows as filtered, and ABORT shows as closed.

nmap -sY 172.16.82.106


References:


Instructor Note

Instructor Notes.


7.2.3.4 NMAP Time-Out Options

  • NMAP - TIME-OUT

T0 T1 T2 T3 T4 T5

Name

Paranoid

Sneaky

Polite

Normal

Aggressive

Insane

min-rtt-timeout

100 ms

100 ms

100 ms

100 ms

100 ms

50 ms

max-rtt-timeout

5 minutes

15 seconds

10 seconds

10 seconds

1250 ms

300 ms

initial-rtt-timeout

5 minutes

15 seconds

1 second

1 second

500 ms

250 ms

max-retries

10

10

10

10

6

2


Timing Template Aggressiveness Scan Speed Timeouts/Probe Behavior Typical Use Case

-T0 (Paranoid)

Very Cautious

Very Slow

Very long timeouts for each probe (e.g., 5+ seconds)

Stealth scans to avoid detection, very slow.

-T1 (Sneaky)

Cautious

Slow

Long timeouts (around 3-5 seconds)

Stealthy scan, used to evade detection.

-T2 (Polite)

Moderate

Slower than normal

Medium timeouts (around 2-4 seconds)

Used when trying to avoid detection but still get results, suitable for scanning busy targets.

-T3 (Normal)

Normal

Normal (default)

Shorter timeouts (around 1-2 seconds)

Default for general-purpose scanning, balancing speed and stealth.

-T4 (Aggressive)

Aggressive

Faster than normal

Short timeouts (under 1 second)

Faster scans, may trigger detection. Ideal for non-sensitive or time-sensitive scans.

-T5 (Insane)

Very Aggressive

Very Fast

Very short timeouts (fractions of a second)

Extremely fast scans, very likely to be detected. Used in scenarios where speed is crucial and detection isn’t a concern.


References:

Nmap Timing Options


Instructor Note

Instructor Notes.


7.2.3.5 NMAP Timing and Performance Options

  • NMAP - DELAY

    • --scan-delay <time> - Minimum delay between probes

      • Nmap to wait at least the given amount of time between each probe it sends to a given host.

    • --max-scan-delay <time> - Max delay between probes

      • Specifies the largest delay that Nmap will allow.

  • NMAP - RATE LIMIT

    • --min-rate <number> - Minimum packets per second

      • Nmap will do its best to send packets as fast as or faster than the given rate.

    • --max-rate <number> - Max packets per second

      • Nmap will try to keep the sending rate at or above the given rate of packets per second.


References:

https://nmap.org/book/man-performance.html


Instructor Note

Instructor Notes.


7.2.4 Firewalking

  • Firewalking

    • Firewalking is a technique used to determine if packets can pass through a firewall without being blocked. It involves sending packets with TTL values set to expire just before reaching the firewall, and observing whether ICMP Time Exceeded messages are returned by the firewall or other devices.

    • Firewalking can help identify open ports and services allowed through a firewall, as well as potential security holes or misconfigurations in firewall rules.

    • Firewalking requires careful selection of TTL values and may not always yield conclusive results, especially if the firewall or intermediate devices are configured to block ICMP messages or hide their presence.

  • Traceroute:

    • Traceroute is a tool used to trace the route packets take from the local machine to a destination host. It works by sending packets with incrementally increasing Time-To-Live (TTL) values and observing the ICMP Time Exceeded messages returned by intermediate routers. ** This allows the traceroute tool to map out the network path taken by packets to reach the destination.

    • Traceroute is commonly used to diagnose network connectivity issues, identify routing loops or delays, and troubleshoot network performance problems.

    • Traceroute does not have the capability to bypass firewalls or security devices, as it relies on the cooperation of intermediate routers to return ICMP Time Exceeded messages.

      traceroute 172.16.82.106
traceroute 172.16.82.106 -p 123
sudo traceroute 172.16.82.106 -I
sudo traceroute 172.16.82.106 -T
sudo traceroute 172.16.82.106 -T -p 443


References:

Firewalk : Can Attackers See Through Your Firewall?


Instructor Note

Instructor Notes.


7.2.5 Netcat

Active External Network Reconnaissance: Scans with Netcat

Netcat, also known as "nc," is a versatile networking utility that allows for reading from and writing to network connections using TCP or UDP protocols. It’s often referred to as the "Swiss Army knife" of networking tools due to its wide range of functionalities. Netcat is available on most Unix-like operating systems, including Linux, macOS, and BSD, as well as on Windows platforms.

Netcat is a tool that can be used to create various inbound/outbound tcp (or udp) connections.

  • Some actions that Netcat can perform:

    • Port Scanning: Netcat can be used to perform basic port scanning by attempting to connect to a range of ports on a target host. This can help identify open ports and services running on a system.

    • File Transfer: Netcat allows for the transfer of files between systems over a network connection. It can act as both a client and a server, facilitating the transfer of data in either direction.

    • Remote Shell Access: Netcat can be used to establish a simple remote shell session between two systems, allowing for command execution and interaction with a remote system’s shell.

    • Port Forwarding: Netcat can be used to set up port forwarding or redirection, allowing traffic destined for one port on a system to be forwarded to another port on a different system.

    • Chat and Messaging: Netcat can facilitate real-time chat or messaging between two systems by establishing a network connection and allowing users to exchange messages.

    • Network Debugging: Netcat can be used for network debugging and troubleshooting purposes, such as testing network connectivity, checking firewall rules, and analyzing network traffic.

It is important to ensure you identify what version of netcat you have installed, this will let you know what options you can and cannot use!


References:

Netcat Official Site

Netcat Man Page


Instructor Note

Instructor Notes.


7.2.5.1 Scanning with Netcat

nc [OPTIONS] [TARGET IP] [TARGET PORT]

nc -h       (Help Menu)
man nc      (Man Pages)

-z : Port scanning mode i.e. zero I/O mode.
-v : Be verbose [use twice -vv to be more verbose].
-n : Use numeric-only IP addresses i.e. do not use DNS to resolve ip addresses.
-w1 : Set time out value to 1. Else it will use the default TCP timeout period of 3-5 seconds.
-u : To switch to UDP.


  • Netcat does not use the (-p) to specify ports to scan. The (-p) is only used with the (-l) to specify a listening port.

    • -p : Specify the local bind port number for listening. Without this option, netcat will listen on a random ephemeral port.

    • -l : Listen mode. Netcat will listen for incoming connections on a random high port or a specified bind port if (-p) is used.

  • To specify the ports to scan (connect) they simply need to be entered after the IP address separated by a space.

    • 21 22 23 80 443

  • You can specify one port or a range of ports using the hyphen (-).

    • 1-1023

  • Netcat does not allow the use of commas (,). To separate ports they must be separate by a space.


  • To scan one TCP port

nc -nzvw1 [TARGET IP] 443
nc -nzvw1 [TARGET IP] 80
nc -nzvw1 [TARGET IP] 21
nc -nzvw1 [TARGET IP] 22
nc -nzvw1 [TARGET IP] 23
nc -nzvw1 [TARGET IP] 25


  • To scan one UDP port

nc -nzuv [TARGET IP] 443
nc -nzuv [TARGET IP] 67
nc -nzuv [TARGET IP] 53
nc -nzuv [TARGET IP] 69
nc -nzuv [TARGET IP] 53


  • To scan a range of ports

## really fast scanner with 1 timeout value ##
netcat -nzvw1 [TARGET IP] 1-1023


  • To scan Discontiguous ports

netcat -nzvw1 [TARGET IP] 21-23 25 80 443


References:

Netcat Official Site

Cyberciti Netcat Example

Netcat Man Page


Instructor Note

Instructor Notes.


7.2.5.2 Netcat Scan Scripts

Netcat scan scripts are custom scripts that leverage Netcat (nc) for performing various types of network scans, such as port scanning, banner grabbing, and more.

Netcat can only scan one IP address at a time and is not able to scan whole network blocks like NMAP can. We can however create a script using a for loop to scan a range of IP address and ports.

Depending on the flavor of linux you are using, netcat open port output can respond with open (Debian) or succeeded (Ubuntu). We will use the grep -E succ|open.

-E (--extended-regexp) - Interpret PATTERNS as extended regular expressions.

  • Create TCP scan.sh file:

nano scan.sh

Copy and paste the following contents into the scan.sh file:

#!/bin/bash

echo "Enter network address (e.g. 192.168.0): "
read net
echo "Enter starting host range (e.g. 1): "
read start
echo "Enter ending host range (e.g. 254): "
read end
echo "Enter ports space-delimited (e.g. 21-23 80): "
read ports

for ((i=$start; $i<=$end; i++))

do
    nc -nvzw1 $net.$i $ports 2>&1 | grep -E 'succ|open' &
done
wait
# (-v) running verbosely (-v on Linux, -vv on Windows),
# (-n) not resolving names. numeric only IP(no D.S)
# (-z) without sending any data. zero-I/O mode(used for scanning)
# (-w1) waiting no more than 1second for a connection to occur
# (2>&1) redirect STDERR to STDOUT. Results of scan are errors and need to redirect to output to grep
# ( | grep -E 'succ|open') for Debian/Ubuntu to display only open connections
# (&) put the scan into the background to run all scan simultaneous
# (wait) wait for all background process to complete before closing

Make the scan.sh file executable:

chmod +x scan.sh


  • Create UDP udpscan.sh file:

#!/bin/bash

echo "Enter network address (e.g. 192.168.0): "
read net
echo "Enter starting host range (e.g. 1): "
read start
echo "Enter ending host range (e.g. 254): "
read end
echo "Enter ports space-delimited (e.g. 21-23 80): "
read ports

for ((i=$start; $i<=$end; i++))

do
    nc -nuvz $net.$i $ports 2>&1 | grep -E 'succ|open'
done

# (-v) running verbosely (-v on Linux, -vv on Windows),
# (-n) not resolving names. numeric only IP(no D.S)
# (-z) without sending any data. zero-I/O mode(used for scanning)
# (-w1) waiting no more than 1second for a connection to occur
# (2>&1) redirect STDERR to STDOUT. Results of scan are errors and need to redirect to output to grep
# ( | grep -E 'succ|open') for Debian/Ubuntu to display only open connections


References:

Netcat Official Site

Cyberciti Netcat Example

Netcat Man Page

Grep Man Page


Instructor Note

Instructor Notes.


7.2.5.3 Netcat One-Liner Scan

A Netcat one-liner scan is a compact command used to scan a range of ports on a target machine in a single line of code. This technique is useful for quickly checking which ports are open on a target system.

  • Vertical Scanning - One, many, or all ports on one target.

    • TCP

      nc -nzvw1 172.16.82.106 21-23 80 2>&1 | grep -E 'succ|open'
      nc -nzvw1 172.16.82.106 1024-65535 2>&1 | grep -E 'succ|open'

    • UDP

      nc -nuzvw1 172.16.82.106 53 67 68 123 2>&1 | grep -E 'succ|open'
      nc -nuzvw1 172.16.82.106 1000-2000 2>&1 | grep -E 'succ|open'

  • Horizontal Scanning - Many or all ports on a range of targets.

    • TCP

      for i in {1..254}; do nc -nvzw1 172.16.82.$i 20-23 80 2>&1 & done | grep -E 'succ|open'

    • UDP

      for i in {1..254}; do nc -nuvzw1 172.16.82.$i 1000-2000 2>&1 & done | grep -E 'succ|open'


References:

Netcat Official Site

Cyberciti Netcat Example

Netcat Man Page

Grep Man Page


Instructor Note

Instructor Notes.

Students should create the Netcat scan scripts on their Opstations.


7.2.5.4 Netcat Banner Grabbing

Netcat banner grabbing is a technique used to obtain information about a service running on a specific port by connecting to it and analyzing the banner it presents. Banners often include details about the software version, operating system, or other configurations that can be useful for network reconnaissance and security assessments.


SSH Ports:

nc 10.10.0.40 22
SSH-2.0-OpenSSH_7.9p1 Debian-10+deb10u4


Telnet ports:

nc -t 10.10.0.40 23
���� ��#��'����������!����Debian GNU/Linux 10
blue-internet-host-student-19 login:


HTTP Ports:

echo "GET /" | nc 10.10.0.40 80
<html>
<h2>This is the webserver on Internet Host</h2>
</html>


References:

Netcat Official Site

Netcat Man Page


Instructor Note

Instructor Notes.


7.2.6 Curl and Wget

Curl

Curl is a Linux command line tool which has the purpose of transfering data to and from servers. It can be used with any of the following protocols (HTTP, FTP, IMAP, POP3, SCP, SFTP, SMTP, TFTP, TELNET and LDAP). For this class you will mainly be using it to interact with service ports in order to see if they return any flags, or to identify what service is actually running on the port with banner grabbing.

Curl defaults to HTTP unless otherwise specified with the appropriate protocol designator.

curl http://www.google.com

curl http://www.google.com:443

curl http://www.google.com/file.txt

curl http://www.google.com/file.txt -o output.txt
curl ftp://123.45.67.8

curl ftp://123.45.67.8/file.txt

curl ftp://123.45.67.8/file.txt -o output.txt

  • Basic Options

    • -o, --output <file>: Write output to <file> instead of stdout.

    • -O, --remote-name: Save the file with the same name as the remote file.

    • -L, --location: Follow redirects if the server responds with a redirect.

    • -C, --continue-at <offset>: Resume a previous file transfer at the given offset.

    • -u, --user <user:password>: Specify the user and password for server authentication.

  • HTTP/HTTPS Options

    • -H, --header <header>: Pass custom header(s) to the server.

    • -d, --data <data>: Send data in a POST request.

    • -F, --form <name=content>: Submit form data.

    • -X, --request <command>: Specify a custom request method to use.

  • Connection Options

    • -I, --head: Fetch the headers only.

    • -N, --no-buffer: Disable buffering of the output stream.

    • -k, --insecure: Allow connections to SSL sites without certificates.

    • --cert <certificate[:password]>: Use the specified certificate file.

    • --key <key>: Use the specified private key file.

  • File Transfer Options

    • -T, --upload-file <file>: Upload a file to the server.

    • --limit-rate <rate>: Limit the transfer rate.

    • --max-redirs <num>: Set the maximum number of redirections to follow.

    • --range <range>: Request a specific range of bytes.

  • Debugging Options

    • -v, --verbose: Make the operation more talkative.

    • --trace <file>: Enable a full trace of the request and response.

    • --trace-ascii <file>: Trace the request and response in ASCII.

  • Authentication Options

    • --basic: Use HTTP Basic authentication.

    • --digest: Use HTTP Digest authentication.

    • --ntlm: Use NTLM authentication.

    • --negotiate: Use HTTP Negotiate (SPNEGO) authentication.

  • Miscellaneous Options

    • -A, --user-agent <string>: Specify a custom user-agent string.

    • -e, --referer <URL>: Specify a referer URL.

    • --proxy <[protocol://]host[:port]>: Use the specified proxy server.

    • -x, --proxy <[protocol://]host[:port]>: Specify a proxy.

  • SSL/TLS Options

    • --ssl: Use SSL/TLS (usually implicit, included in default behavior for HTTPS).

    • --tlsv1.0, --tlsv1.1, --tlsv1.2, --tlsv1.3: Use specific versions of TLS.

  • Output Options

    • -s, --silent: Silent mode (no output).

    • --stderr <file>: Redirect stderr to a file.


Wget

Wget works much the same way as curl, only it is used to download files from the server instead of just reading the content that is there.

Also like curl, it defaults to HTTP, but can be used with HTTPS and FTP. Wget can follow links in HTML, XHTML, and CSS pages.

Using the option of -r will download everything at the location in the folder structure and will place it in a new folder on your local system which is named after the url or IP address where the files were downloaded.

wget -r http://172.16.82.106

wget -r http://172.16.82.106:80
wget -r ftp://172.16.82.106

wget -r ftp://172.16.82.106 --user=student --password=password

  • Basic Options

    • -O, --output-document=<file>: Write the downloaded content to <file> instead of stdout.

    • -o, --output-file=<file>: Log messages to <file>.

    • -a, --append-output=<file>: Append messages to <file>.

  • Downloading Options

    • -c, --continue: Continue getting a partially-downloaded file.

    • -N, --timestamping: Download only files that are newer than the local copies.

    • -r, --recursive: Download the site recursively.

      • Will use anonymous to authenticate unless --user=<user> and --password=<password> is used.

    • -l, --level=<number>: Set the maximum recursion depth.

    • -np, --no-parent: Don’t ascend to the parent directory when downloading recursively.

    • -P, --directory-prefix=<prefix>: Save files to <prefix> directory.

    • -nc, --no-clobber: Skip files that already exist.

  • HTTP Options

    • --http-user=<user>: Specify HTTP user.

    • --http-password=<password>: Specify HTTP password.

    • --header=<header>: Add custom HTTP header.

    • --no-check-certificate: Skip SSL certificate checks.

  • FTP Options

    • --ftp-user=<user>: Specify FTP user.

    • --ftp-password=<password>: Specify FTP password.

    • --no-iri: Disable Internationalized Resource Identifiers.

  • Proxy Options

    • --proxy=<proxy>: Use the specified proxy server.

    • --no-proxy: Do not use a proxy for any downloads.

  • Authentication Options

    • --user=<user>: Specify the username for authentication.

    • --password=<password>: Specify the password for authentication.

  • File Handling Options

    • --limit-rate=<rate>: Limit the download speed.

    • --wait=<seconds>: Wait the specified number of seconds between downloads.

    • --random-wait: Randomize wait times to avoid server overload.

  • Miscellaneous Options

    • -q, --quiet: Suppress output.

    • -v, --verbose: Print detailed information.

    • -h, --help: Display help information.

    • --version: Show version information.

    • --no-verbose: Suppress non-error messages.

  • Advanced Options

    • --mirror: Enable options suitable for mirroring websites (equivalent to -r -N -l inf --no-remove-listing).

    • --convert-links: Convert the links in downloaded HTML files for offline viewing.

    • --backup-converted: Backup files before converting them.

    • --timestamping: Download only files that are newer than the local copy.

    • --no-parent: Don’t ascend to the parent directory.


References:

Curl Man Page

Wget Man Page


Instructor Note

Instructor Notes.


7.3 Describe Methods Used for Passive Internal Network Reconnaissance


800


Passive internal network reconnaissance involves discreetly acquiring information about an organization’s internal network infrastructure without engaging directly with the systems. This reconnaissance method is commonly employed in the early phases of cybersecurity assessments, penetration testing, or ethical hacking within the internal network environment. In contrast to active reconnaissance, which entails the use of probes and requests, passive internal network reconnaissance centers on the unobtrusive collection of data without causing alerts or disruptions to the network’s functionality. In this phase we commonly use commands on the internal system itself to collect information.


References:


Instructor Note

Instructor Notes.


7.3.1 Packet Sniffers

Passive Internal Network Reconnaissance: Traffic Sniffing

  • Sniffing network traffic is one of the most useful passive techniques, but possibly the most involved. Even without a SPAN port, useful traffic is broadcast on a switched network. ARP/NDP and DHCP requests tell about hosts; CDP and STP inform about infrastructure devices; and the Server Message Block (SMB) Protocol is always seeking peers. If the point of presence is a server, other hosts send traffic to it, then use TTLs and ephemeral ports to guess what type of OS is generating the traffic. Passive OS fingerprinting gives a much more precise guess. Remember, TTLs, MAC addresses, and IP addresses can tell if the sending system is on the local network or has to be routed.

  • Capturing raw signals from the wire is an easy way to learn about a network and how devices and applications communicate. Hardware-based sniffers are best for capturing raw signals from the wire, though they range in price and accessibility. Software-based sniffers rely on the NIC of the host system to relay traffic through the OS and usually cannot see all signals on the wire, such as the preamble and a frame’s CRC, limiting their use in some situations. Another limiting factor of software sniffers is the operating mode of the NIC, of which two exist:

    • Non-promiscuous — default mode for most NICs. Only passes traffic destined for its MAC address, its multicast groups, or broadcast.

    • Promiscuous — the NIC passes all signals to the OS. Most Unix-based systems support promiscuous mode natively; Windows requires additional drivers to enable promiscuous mode, such as WinPcap. Most software sniffers use the standard BPF syntax. The most common output file format is the standard .pcap file (packet capture).

    • tcpdump — A command-line tool native to most Linux systems and has been ported to Windows and many Berkeley Software Distribution (BSD)-based systems.

    • Wireshark — A graphical user interface (GUI)-based tool with its own display filter syntax. Available on Windows and most Linux distributions.


References:


Instructor Note

Instructor Notes.


7.3.2 Native Host Tools

Passive Internal Network Reconnaissance: Information Gathering on Hosts


References:


Instructor Note


7.3.2.1 IP Address

Windows: ipconfig
Linux: ifconfig (depreciated)
Linux: ip address

  • Windows:

    • The ipconfig command is a network configuration command used primarily in Windows operating systems. It displays and manages the IP configuration of network interfaces, providing details such as IP addresses, subnet masks, and default gateways.

C:\Users\Username>ipconfig

Windows IP Configuration

Ethernet adapter Ethernet:

   Connection-specific DNS Suffix  . : example.local
   Link-local IPv6 Address . . . . . : fe80::1c7b:8f5e:1f8d:9a2e%12
   IPv4 Address. . . . . . . . . . . : 192.168.1.100
   Subnet Mask . . . . . . . . . . . : 255.255.255.0
   Default Gateway . . . . . . . . . : 192.168.1.1

Wireless LAN adapter Wi-Fi:

   Connection-specific DNS Suffix  . : example.local
   Link-local IPv6 Address . . . . . : fe80::14b2:6c8a:bdc9:78e5%15
   IPv4 Address. . . . . . . . . . . : 192.168.1.101
   Subnet Mask . . . . . . . . . . . : 255.255.255.0
   Default Gateway . . . . . . . . . : 192.168.1.1

Tunnel adapter Teredo Tunneling Pseudo-Interface:

   Connection-specific DNS Suffix  . :
   IPv6 Address. . . . . . . . . . . : 2001:0:9d38:6ab8:38e1:3f57:feb2:a35f
   Link-local IPv6 Address . . . . . : fe80::38e1:3f57:feb2:a35f%16
   Default Gateway . . . . . . . . . :

  • Linux:

    • The ifconfig command is a system administration utility in Unix-like operating systems for network interface configuration. It allows you to configure, manage, and query network interface parameters.

    • 4.2BSD (1983): The introduction of the TCP/IP stack in 4.2BSD made it necessary to have tools to configure and manage network interfaces. ifconfig was developed as one of these tools to allow system administrators to configure IP addresses, netmasks, and other parameters for network interfaces.

    • Began to be deprecated in the early 2000s when the ip command, part of the iproute2 package, was introduced as a more powerful and versatile replacement.

    • 1999: The iproute2 package, which includes the ip command, was introduced in the late 1990s as part of the development of more advanced networking features in the Linux kernel. The ip command provided more comprehensive network management capabilities, including support for advanced features like policy routing, network namespaces, and handling multiple addresses on interfaces.

    • Early 2000s: Linux distributions started to include iproute2 as the preferred tool for network configuration. However, ifconfig continued to be widely used due to its simplicity and familiarity.

    • 2009: The official deprecation of ifconfig began to be reflected in documentation and by the Linux community, with a strong recommendation to use the ip command instead.

    • 2010s: Major Linux distributions started to phase out ifconfig from default installations:

      • Debian/Ubuntu: By the release of Ubuntu 18.04 LTS (2018) and Debian 9 Stretch (2017), ifconfig was no longer installed by default, and users were encouraged to use the ip command.

      • Red Hat/CentOS: Similarly, by the release of CentOS/RHEL 7 (2014), the ip command became the standard, and ifconfig was relegated to legacy status.

$ ifconfig

eth0      Link encap:Ethernet  HWaddr 00:1a:2b:3c:4d:5e
          inet addr:192.168.1.100  Bcast:192.168.1.255  Mask:255.255.255.0
          inet6 addr: fe80::21a:2bff:fe3c:4d5e/64 Scope:Link
          UP BROADCAST RUNNING MULTICAST  MTU:1500  Metric:1
          RX packets:105674 errors:0 dropped:0 overruns:0 frame:0
          TX packets:98876 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:1000
          RX bytes:10214532 (10.2 MB)  TX bytes:12796432 (12.7 MB)
          Interrupt:20 Memory:fe800000-fe820000

lo        Link encap:Local Loopback
          inet addr:127.0.0.1  Mask:255.0.0.0
          inet6 addr: ::1/128 Scope:Host
          UP LOOPBACK RUNNING  MTU:65536  Metric:1
          RX packets:5432 errors:0 dropped:0 overruns:0 frame:0
          TX packets:5432 errors:0 dropped:0 overruns:0 carrier:0
          collisions:0 txqueuelen:1000
          RX bytes:431232 (431.2 KB)  TX bytes:431232 (431.2 KB)

  • Linux:

    • The ip address command is part of the ip command suite, which is included in the iproute2 package in Linux. This command is used to display and manage IP addresses, network interfaces, and their properties.

    • Early 2000s: Major Linux distributions started adopting iproute2 as the preferred toolset for network configuration. As iproute2 offered more advanced features, it gradually replaced the older net-tools package, which included ifconfig, route, and other utilities.

    • 2000s: Distributions such as Debian, Red Hat, and SuSE began integrating iproute2 into their default installations. ip became the standard tool for network management.

    • 2007: By the time of the release of Ubuntu 7.10 (Gutsy Gibbon) and similar releases from other distributions, iproute2 was widely adopted. ifconfig was still included for backward compatibility, but ip was encouraged for new scripts and configuration tasks.

    • 2010s: As Linux distributions continued to evolve, iproute2 became the default networking tool, and ifconfig was eventually removed from the default installations of many distributions. By the time of releases like Ubuntu 18.04 LTS and Debian 9, ifconfig was no longer installed by default, reflecting the shift towards iproute2.

student@internet-host-student-01:~$ ip address
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
    inet6 ::1/128 scope host
       valid_lft forever preferred_lft forever
2: eth0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1450 qdisc mq state UP group default qlen 1000
    link/ether fa:16:3e:b0:af:e0 brd ff:ff:ff:ff:ff:ff
    inet 10.10.0.40/27 brd 10.10.0.63 scope global eth0
       valid_lft forever preferred_lft forever
    inet6 fe80::f816:3eff:feb0:afe0/64 scope link
       valid_lft forever preferred_lft forever


References:

https://wiki.linuxfoundation.org/networking/iproute2


Instructor Note

Instructor Notes.


7.3.2.2 System DNS

Linux: /etc/resolv.conf
Windows: ipconfig /displaydns
Windows: ipconfig /all

  • Displays all current TCP/IP network configuration values and refreshes Dynamic Host Configuration Protocol (DHCP) and Domain Name System (DNS) settings. Used without parameters, ipconfig displays Internet Protocol version 4 (IPv4) and IPv6 addresses, subnet mask, and default gateway for all adapters. Additional provided valuable:

  • Linux:

    • The /etc/resolv.conf file is a critical configuration file in Unix-like operating systems, including Linux, that defines how DNS (Domain Name System) resolution is handled on the system. It specifies the nameservers that the system should use to resolve domain names to IP addresses.

cat /etc/resolv.conf
nameserver 8.8.8.8
nameserver 8.8.4.4
search example.com
domain example.com

  • Windows:

    • The ipconfig /displaydns command is used on Windows operating systems to display the contents of the DNS resolver cache. This cache stores DNS query results that the system has previously resolved, allowing for faster access to frequently visited websites by avoiding repeated DNS lookups.

ipconfig /displaydns

Windows IP Configuration

example.com
----------------------------------------
    Record Name . . . . . . . . . . . : example.com
    Record Type . . . . . . . . . . . : 1
    Time To Live . . . . . . . . . . . : 3600
    Data Length . . . . . . . . . . . : 4
    IP Address . . . . . . . . . . . : 93.184.216.34

anotherdomain.com
----------------------------------------
    Record Name . . . . . . . . . . . : anotherdomain.com
    Record Type . . . . . . . . . . . : 1
    Time To Live . . . . . . . . . . . : 3600
    Data Length . . . . . . . . . . . : 4
    IP Address . . . . . . . . . . . : 192.0.2.1

  • Windows:

    • The ipconfig /all command in Windows provides detailed information about the network configuration for all network interfaces on the system. This command displays comprehensive details including IP addresses, subnet masks, gateways, DNS servers, and other networking information.

ipconfig /all

Windows IP Configuration

   Host Name . . . . . . . . . . . . . . . : my-computer
   Primary Dns Suffix . . . . . . . . . . . : example.local
   Node Type . . . . . . . . . . . . . . . : Hybrid
   IP Routing Enabled. . . . . . . . . . . : No
   WINS Proxy Enabled. . . . . . . . . . . : No

Ethernet adapter Ethernet:

   Connection-specific DNS Suffix  . . . . . : example.local
   Description . . . . . . . . . . . . . : Intel(R) Ethernet Connection
   Physical Address. . . . . . . . . . . : 00-1A-2B-3C-4D-5E
   DHCP Enabled. . . . . . . . . . . . : Yes
   Autoconfiguration Enabled . . . . . . : Yes
   Link-local IPv6 Address . . . . . . . : fe80::1a2b:3c4d:5e6f%12
   IPv4 Address. . . . . . . . . . . . : 192.168.1.100
   Subnet Mask . . . . . . . . . . . : 255.255.255.0
   Default Gateway . . . . . . . . . . : 192.168.1.1
   DHCP Server . . . . . . . . . . . : 192.168.1.1
   DNS Servers . . . . . . . . . . . : 8.8.8.8
                                        8.8.4.4
   Lease Obtained. . . . . . . . . . . : Wednesday, August 21, 2024 10:00:00 AM
   Lease Expires . . . . . . . . . . . : Thursday, August 22, 2024 10:00:00 AM

Wireless LAN adapter Wi-Fi:

   Connection-specific DNS Suffix  . . . . . : example.local
   Description . . . . . . . . . . . . . : Intel(R) WiFi 6 AX200 160MHz
   Physical Address. . . . . . . . . . . : 00-1A-2B-3C-4D-5F
   DHCP Enabled. . . . . . . . . . . . : Yes
   Autoconfiguration Enabled . . . . . . : Yes
   Link-local IPv6 Address . . . . . . . : fe80::1a2b:3c4d:5f6g%13
   IPv4 Address. . . . . . . . . . . . : 192.168.1.101
   Subnet Mask . . . . . . . . . . . : 255.255.255.0
   Default Gateway . . . . . . . . . . : 192.168.1.1
   DHCP Server . . . . . . . . . . . : 192.168.1.1
   DNS Servers . . . . . . . . . . . : 8.8.8.8
                                        8.8.4.4
   Lease Obtained. . . . . . . . . . . : Wednesday, August 21, 2024 10:05:00 AM
   Lease Expires . . . . . . . . . . . : Thursday, August 22, 2024 10:05:00 AM

Tunnel adapter Teredo Tunneling Pseudo-Interface:

   Connection-specific DNS Suffix  . . . . . :
   Description . . . . . . . . . . . . . : Teredo Tunneling Pseudo-Interface
   Physical Address. . . . . . . . . . . : N/A
   DHCP Enabled. . . . . . . . . . . . : No
   Autoconfiguration Enabled . . . . . . : Yes
   IPv6 Address. . . . . . . . . . . . : 2001:0:abcd:1234:5678:90ab:cdef:1234
   Link-local IPv6 Address . . . . . . . : fe80::abcd:1234:5678:90ab%14
   Default Gateway . . . . . . . . . . : N/A


References:


Instructor Note

Instructor Notes.


7.3.2.3 ARP (Address Resolution Protocol)

Windows: arp -a
Linux: arp -a (depreciated)
Linux: ip neighbor

  • The arp -a command is used in Windows, Linux, and macOS to display the Address Resolution Protocol (ARP) cache. The ARP cache contains mappings of IP addresses to MAC (Media Access Control) addresses on the local network. This helps facilitate communication within a local network by resolving IP addresses to hardware addresses.

  • Windows:

    • The arp -a command on Windows is used to display the Address Resolution Protocol (ARP) table, which maps IP addresses to MAC addresses on the local network. This table helps in determining the hardware address of devices within the same network segment.

arp -a

Interface: 192.168.1.10 --- 0x6
  Internet Address      Physical Address      Type
  192.168.1.1          00-1a-2b-3c-4d-5e     dynamic
  192.168.1.15         00-1e-2f-3d-4c-5b     dynamic
  192.168.1.20         00-2f-3a-4b-5c-6d     dynamic

  • Linux:

    • The ip neighbor command, part of the iproute2 suite on Linux, is used to manage and display the ARP (Address Resolution Protocol) or NDP (Neighbor Discovery Protocol) table entries. These tables map IP addresses to MAC addresses for IPv4 (ARP) and IPv6 (NDP) communication.

student@internet-host-student-01:~$ ip neighbor
10.10.0.62 dev eth0 lladdr fa:16:3e:b2:eb:3b REACHABLE


References:


Instructor Note

Instructor Notes.


7.3.2.4 Netstat/ss

Windows: netstat
Linux: netstat (depreciated)
Linux: ss

  • netstat (Network Statistics) is a legacy tool that provides information about network connections, routing tables, interface statistics, and more. It is available on various operating systems including Linux, Windows, and macOS.

  • ss (Socket Statictics) is a more modern utility that is part of the iproute2 package on Linux. It provides detailed information about network sockets and is designed to be faster and more efficient than netstat.

    • Example options useful for both netstat and ss:

      • -a = Displays all active connections and ports.

      • -n = No determination of protocol names. Shows 22 not SSH.

      • -t = Display only TCP connections.

      • -u = Display only UDP connections.

      • -p = Shows which processes are using which sockets.

      • -l = Displays only listening sockets.

      • -r = Display routing information.

      • -e = Display extended socket information.

      • -h = Display help message with usage information.

      • -s = Display summary statistics.

      • -o = Show timer information (TCP).

student@internet-host-student-01:~$ ss -antlp
State       Recv-Q Send-Q                 Local Address:Port                                Peer Address:Port
LISTEN      0      128                                *:23                                             *:*
LISTEN      0      128                        127.0.0.1:6010                                           *:*
LISTEN      0      128                        127.0.0.1:6011                                           *:*
LISTEN      0      128                                *:80                                             *:*
LISTEN      0      128                                *:22                                             *:*
LISTEN      0      128                              ::1:6010                                          :::*
LISTEN      0      128                              ::1:6011                                          :::*
LISTEN      0      2                                 :::3389                                          :::*
LISTEN      0      128                               :::80                                            :::*
LISTEN      0      32                                :::21                                            :::*
LISTEN      0      128                               :::22                                            :::*
LISTEN      0      2                                ::1:3350                                          :::*


References:

ss Man page

netstat Man page


Instructor Note

Instructor Notes.


7.3.2.5 Services File

Windows: %SystemRoot%\system32\drivers\etc\services
Linux/Unix: /etc/services

  • The services file provides a list of well-known port numbers mapped to each commonly associated service and any optional aliases that the service may use. Each OS maintains this file, which follows a simple structure.

  • Keep in mind that the port mappings are just a simple translation from port to service name. It is possible for an HTTP server to be listening on port 23, but the OS which is using the services file would still list telnet.

  • services file format:

<service> <port>/<protocol> <aliases> #Comments

Example:

http 80/tcp www www-http #World Wide Web

In this example, TCP port 80 is associated with the http service and two optional aliases, www and www-http, are given. The services file is located most commonly in the /etc/ directory and the table below shows common locations by OS.

Protocol & Port Common Service
TCP 21 FTP
TCP 22 Secure Shell (SSH)
TCP 23 Telnet
TCP 25 SMTP (email)
TCP/UDP 53 DNS
UDP 67/68 DHCP
TCP 80 HTTP
TCP 110 POP3 (email)
UDP 123 Network Time
Protocol (NTP)
TCP 443 HTTPS
TCP 445 Server Message Block (SMB) (File Sharing)
UDP 514 Syslog


References:

https://man7.org/linux/man-pages/man5/services.5.html

https://www.cs.clemson.edu/course/cpsc424/material/TCP%20UDP%20Services/etc-services.pdf

https://www.ibm.com/docs/en/rational-synergy/7.2.1?topic=server-services-file


Instructor Note

Instructor Notes.


7.3.2.6 Operating System Information

Linux: cat /etc/os-release
Linux: lsb_release -a
Linux: uname -a
Windows: systeminfo
Windows: ver
Windows: wmic os get Caption, Version, BuildNumber, OSArchitecture

Linux

To determine Linux operating system information from the command line, you can use various commands depending on the specific information you need:

  • Displays various details about the operating system, including name, version, and ID:

cat /etc/os-release

  • Provides detailed information about the Linux distribution, including distributor ID, description, release, and codename:

lsb_release -a

  • Provides the kernel name, network node hostname, kernel release, kernel version, machine hardware name, processor type, hardware platform, and the operating system:

uname -a

  • Displays the kernel version and other relevant details:

cat /proc/version

  • Shows the system architecture. It shows whether the system is running on a 32-bit or 64-bit architecture:

arch

  • Hardware Information:

lshw            : Lists detailed hardware configuration.
lscpu           : Displays CPU information.
lsblk           : Lists block devices (disk drives).

Windows

To determine Windows operating system information from the command line:

  • Operating System Version:

    • Displays detailed system information, including OS version, build number, and installed hotfixes.

systeminfo

  • Displays the Windows version:

ver

  • System Architecture:

wmic os get osarchitecture

  • Hardware Information:

wmic cpu get name                 : Displays CPU information.
wmic diskdrive get caption        : Lists disk drives.
wmic memorychip get capacity      : Shows installed memory capacity.


References:


Instructor Note

Instructor Notes.


7.3.2.7 Local Processes

Windows: tasklist
Linux/Unix: top
Linux/Unix: ps

  • Windows:

    • The tasklist command is used in Windows to display a list of currently running processes on a local or remote computer. It provides details such as the process ID (PID), memory usage, and executable name.

Image Name                     PID Session Name        Session#    Mem Usage
========================= ======== ================ =========== ============
System Idle Process              0 Services                   0         24 K
System                           4 Services                   0        208 K
smss.exe                       408 Services                   0        568 K
csrss.exe                      516 Services                   0      1,092 K
wininit.exe                     624 Services                   0        832 K
services.exe                    648 Services                   0      1,156 K
lsass.exe                       664 Services                   0      1,576 K
svchost.exe                     728 Services                   0      1,788 K
svchost.exe                     844 Services                   0      1,856 K
explorer.exe                    992 Console                    1      9,220 K
cmd.exe                        1240 Console                    1      5,680 K

  • Linux:

    • The ps command is used on Unix-like operating systems (such as Linux and macOS) to display information about active processes. Unlike top, which provides a dynamic, real-time view of processes, ps provides a snapshot of current processes.

      • -e - Select all processes. Identical to -A.

      • -l - Long format. The -y option is often useful with this.

      • -f - Do full-format listing.

student@internet-host-student-01:~$ ps -elf
F S UID        PID  PPID  C PRI  NI ADDR SZ WCHAN  STIME TTY          TIME CMD
4 S root         1     0  0  80   0 - 14322 -      Jul01 ?        00:00:43 /sbin/init
1 S root         2     0  0  80   0 -     0 -      Jul01 ?        00:00:00 [kthreadd]
1 S root         3     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [ksoftirqd/0]
1 S root         5     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [kworker/0:0H]
1 S root         7     2  0  80   0 -     0 -      Jul01 ?        00:00:19 [rcu_sched]
1 S root         8     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [rcu_bh]
1 S root         9     2  0 -40   - -     0 -      Jul01 ?        00:00:02 [migration/0]
1 S root        10     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [lru-add-drain]
5 S root        11     2  0 -40   - -     0 -      Jul01 ?        00:00:01 [watchdog/0]
1 S root        12     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [cpuhp/0]
1 S root        13     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [cpuhp/1]
5 S root        14     2  0 -40   - -     0 -      Jul01 ?        00:00:01 [watchdog/1]
1 S root        15     2  0 -40   - -     0 -      Jul01 ?        00:00:01 [migration/1]
1 S root        16     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [ksoftirqd/1]
1 S root        18     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [kworker/1:0H]
5 S root        19     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [kdevtmpfs]
1 S root        20     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [netns]
1 S root        21     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [khungtaskd]
1 S root        22     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [oom_reaper]
1 S root        23     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [writeback]
1 S root        24     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [kcompactd0]
1 S root        26     2  0  85   5 -     0 -      Jul01 ?        00:00:00 [ksmd]
1 S root        27     2  0  99  19 -     0 -      Jul01 ?        00:00:00 [khugepaged]
1 S root        28     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [crypto]
1 S root        29     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [kintegrityd]
1 S root        30     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        31     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [kblockd]
1 S root        32     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [devfreq_wq]
1 S root        33     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [watchdogd]
1 S root        34     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [kswapd0]
1 S root        35     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [vmstat]
1 S root        47     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [kthrotld]
1 S root        48     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [ipv6_addrconf]
1 S root        84     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        85     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        86     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        87     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [ata_sff]
1 S root        88     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        90     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        91     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        92     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root        93     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root       120     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root       121     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [scsi_eh_0]
1 S root       122     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [scsi_tmf_0]
1 S root       123     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [scsi_eh_1]
1 S root       124     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [scsi_tmf_1]
1 S root       126     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [bioset]
1 S root       157     2  0  60 -20 -     0 -      Jul01 ?        00:00:04 [kworker/1:1H]
1 S root       159     2  0  80   0 -     0 -      Jul01 ?        00:00:09 [jbd2/vda1-8]
1 S root       160     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [ext4-rsv-conver]
1 S root       206     2  0  60 -20 -     0 -      Jul01 ?        00:00:06 [kworker/0:1H]
4 S root       208     1  0  80   0 - 16130 -      Jul01 ?        00:00:29 /lib/systemd/systemd-journald
1 S root       215     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [kauditd]
4 S root       222     1  0  80   0 - 11662 -      Jul01 ?        00:00:00 /lib/systemd/systemd-udevd
1 S root       270     2  0  80   0 -     0 -      Jul01 ?        00:00:00 [hwrng]
1 S root       274     2  0  60 -20 -     0 -      Jul01 ?        00:00:00 [ttm_swap]
1 S root       424     1  0  80   0 -  5089 -      Jul01 ?        00:00:02 /sbin/dhclient -4 -v -pf /run/dhclient.eth0.pid -lf
4 S root       531     1  0  80   0 -  9515 -      Jul01 ?        00:00:01 /lib/systemd/systemd-logind
4 S root       532     1  0  80   0 -  9048 -      Jul01 ?        00:00:26 /usr/sbin/inetd
4 S root       536     1  0  80   0 -  7400 -      Jul01 ?        00:00:01 /usr/sbin/cron -f
4 S avahi      537     1  0  80   0 - 11753 -      Jul01 ?        00:00:00 avahi-daemon: running [internet-host-student-20.loc
4 S root       538     1  0  80   0 -  2782 -      Jul01 ?        00:00:00 /bin/bash /usr/share/cctc/autorun.sh
4 S root       542     1  0  80   0 - 62528 -      Jul01 ?        00:00:06 /usr/sbin/rsyslogd -n
0 S root       546   538  0  80   0 -  7170 -      Jul01 ?        00:00:00 /usr/bin/python3 /usr/share/cctc/datagram_socket_re
1 S avahi      548   537  0  80   0 - 11753 -      Jul01 ?        00:00:00 avahi-daemon: chroot helper
4 S root       549     1  0  80   0 -  8981 -      Jul01 ?        00:00:16 /usr/sbin/irqbalance --foreground
4 S rtkit      550     1  0  81   1 - 44327 -      Jul01 ?        00:00:06 /usr/lib/rtkit/rtkit-daemon
4 S unscd      556     1  0  80   0 -  4201 -      Jul01 ?        00:00:02 /usr/sbin/nscd -d
4 S message+   557     1  0  80   0 -  9205 -      Jul01 ?        00:02:00 /usr/bin/dbus-daemon --system --address=systemd: --
4 S root       614     1  0  80   0 -  1456 -      Jul01 ttyS0    00:00:00 /sbin/agetty --keep-baud 115200,38400,9600 ttyS0 vt
4 S root       615     1  0  80   0 -  1110 -      Jul01 tty1     00:00:00 /sbin/agetty --noclear tty1 linux
4 S root       621     1  0  80   0 - 72452 -      Jul01 ?        00:00:00 /usr/sbin/lightdm
1 S root       632     1  0  80   0 -  6622 -      Jul01 ?        00:00:00 /usr/sbin/xrdp-sesman
5 S root       637     1  0  80   0 - 37772 -      Jul01 ?        00:00:00 nginx: master process /usr/sbin/nginx -g daemon on;
5 S www-data   638   637  0  80   0 - 37856 -      Jul01 ?        00:00:00 nginx: worker process
5 S www-data   639   637  0  80   0 - 37856 -      Jul01 ?        00:00:44 nginx: worker process
5 S ntp        653     1  0  80   0 - 24463 -      Jul01 ?        00:00:36 /usr/sbin/ntpd -p /var/run/ntpd.pid -g -u 105:109
1 S xrdp       661     1  0  80   0 -  5730 -      Jul01 ?        00:00:03 /usr/sbin/xrdp
4 S root       668     1  0  80   0 - 15915 -      Jul01 ?        00:00:03 /usr/sbin/sshd -D
4 S root       671   621  0  80   0 - 93765 -      Jul01 tty7     00:00:13 /usr/lib/xorg/Xorg :0 -seat seat0 -auth /var/run/li
5 S root       726     1  0  80   0 - 44033 -      Jul01 ?        00:05:02 /usr/bin/python -O /usr/share/wicd/daemon/wicd-daem
0 S root       740   726  0  80   0 - 25129 -      Jul01 ?        00:02:06 /usr/bin/python -O /usr/share/wicd/daemon/monitor.p
4 S root       745   621  0  80   0 - 58809 -      Jul01 ?        00:00:00 lightdm --session-child 18 21
4 S lightdm    751     1  0  80   0 - 14132 -      Jul01 ?        00:00:00 /lib/systemd/systemd --user
5 S lightdm    776   751  0  80   0 - 21741 -      Jul01 ?        00:00:00 (sd-pam)
4 S lightdm    784   745  0  80   0 - 154428 -     Jul01 ?        00:02:32 /usr/sbin/lightdm-gtk-greeter
0 S lightdm    808     1  0  80   0 - 87168 -      Jul01 ?        00:00:00 /usr/lib/at-spi2-core/at-spi-bus-launcher --launch-
0 S lightdm    813   751  0  80   0 -  9137 -      Jul01 ?        00:00:00 /usr/bin/dbus-daemon --session --address=systemd: -
0 S lightdm    816   808  0  80   0 -  9137 -      Jul01 ?        00:00:00 /usr/bin/dbus-daemon --config-file=/usr/share/defau
0 S lightdm    825     1  0  80   0 - 55077 -      Jul01 ?        00:00:00 /usr/lib/at-spi2-core/at-spi2-registryd --use-gnome
0 S lightdm    829   751  0  80   0 - 71040 -      Jul01 ?        00:00:00 /usr/lib/gvfs/gvfsd
0 S lightdm    839   751  0  80   0 - 88036 -      Jul01 ?        00:00:00 /usr/lib/gvfs/gvfsd-fuse /run/user/112/gvfs -f -o b
0 S root       997   621  0  80   0 - 22394 -      Jul01 ?        00:00:00 lightdm --session-child 14 21
1 S root      9663     2  0  80   0 -     0 -      00:00 ?        00:00:08 [kworker/0:2]
0 S student  16098 18446  0  80   0 -  9137 SyS_ep Jul06 ?        00:00:00 /usr/bin/dbus-daemon --session --address=systemd: -
0 S student  16103 18446  0  80   0 - 71040 SyS_po Jul06 ?        00:00:00 /usr/lib/gvfs/gvfsd
0 S student  16108 18446  0  80   0 - 88036 -      Jul06 ?        00:00:00 /usr/lib/gvfs/gvfsd-fuse /run/user/1001/gvfs -f -o
4 S root     18441   668  0  80   0 - 25361 -      Jul02 ?        00:00:00 sshd: student [priv]
4 S student  18446     1  0  80   0 - 14135 SyS_ep Jul02 ?        00:00:00 /lib/systemd/systemd --user
5 S student  18448 18446  0  80   0 - 21741 -      Jul02 ?        00:00:00 (sd-pam)
5 S student  18456 18441  0  80   0 - 25361 -      Jul02 ?        00:00:01 sshd: student@pts/0
0 S student  18457 18456  0  80   0 -  3172 -      Jul02 pts/0    00:00:00 -bash
4 S root     18492 18457  0  80   0 - 13918 -      Jul02 pts/0    00:00:00 sudo su
4 S root     18497 18492  0  80   0 - 14259 -      Jul02 pts/0    00:00:00 su
4 S root     18498 18497  0  80   0 -  3157 -      Jul02 pts/0    00:00:00 bash
1 S root     19773     2  0  80   0 -     0 -      Jul05 ?        00:00:05 [kworker/u4:1]
5 S proftpd  20188     1  0  80   0 - 31669 -      Jul04 ?        00:00:02 proftpd: (accepting connections)
1 S root     21128     2  0  60 -20 -     0 -      Jul06 ?        00:00:00 [cfg80211]
4 S root     23465   668  0  80   0 - 25361 -      13:49 ?        00:00:00 sshd: student [priv]
5 S student  23471 23465  0  80   0 - 25361 -      13:49 ?        00:00:00 sshd: student@pts/1
0 S student  23472 23471  0  80   0 -  3172 core_s 13:49 pts/1    00:00:00 -bash
1 S root     23473     2  0  80   0 -     0 -      13:49 ?        00:00:00 [kworker/u4:0]
1 S root     23697     2  0  80   0 -     0 -      14:03 ?        00:00:00 [kworker/1:0]
4 S root     24352   668  0  80   0 - 25361 -      14:43 ?        00:00:00 sshd: student [priv]
5 S student  24360 24352  0  80   0 - 25361 -      14:43 ?        00:00:00 sshd: student@pts/2
0 S student  24361 24360  0  80   0 -  3172 -      14:43 pts/2    00:00:00 -bash
1 S root     24671     2  0  80   0 -     0 -      15:00 ?        00:00:00 [kworker/0:0]
1 S root     24686     2  0  80   0 -     0 -      15:01 ?        00:00:00 [kworker/1:2]
1 S root     24762     2  0  80   0 -     0 -      15:06 ?        00:00:00 [kworker/0:1]
0 R student  24773 24361  0  80   0 -  7450 -      15:06 pts/2    00:00:00 ps -elf

  • Linux:

    • The top command is a widely used utility on Unix-like operating systems (such as Linux and macOS) that provides a real-time, dynamic view of system processes. It displays information about system performance, running processes, and resource utilization.

student@internet-host-student-01:~$ top

top - 15:08:01 up 7 days, 18:12,  3 users,  load average: 0.01, 0.06, 0.07
Tasks: 121 total,   1 running, 120 sleeping,   0 stopped,   0 zombie
%Cpu(s):  0.0 us,  0.1 sy,  0.0 ni, 99.1 id,  0.8 wa,  0.0 hi,  0.0 si,  0.0 st
KiB Mem :  4050832 total,  3088400 free,   149388 used,   813044 buff/cache
KiB Swap:        0 total,        0 free,        0 used.  3560824 avail Mem

  PID USER      PR  NI    VIRT    RES    SHR S  %CPU %MEM     TIME+ COMMAND
    1 root      20   0   57288   7120   5344 S   0.0  0.2   0:43.38 systemd
    2 root      20   0       0      0      0 S   0.0  0.0   0:00.17 kthreadd
    3 root      20   0       0      0      0 S   0.0  0.0   0:00.06 ksoftirqd/0
    5 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 kworker/0:0H
    7 root      20   0       0      0      0 S   0.0  0.0   0:19.07 rcu_sched
    8 root      20   0       0      0      0 S   0.0  0.0   0:00.00 rcu_bh
    9 root      rt   0       0      0      0 S   0.0  0.0   0:02.24 migration/0
   10 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 lru-add-drain
   11 root      rt   0       0      0      0 S   0.0  0.0   0:01.63 watchdog/0
   12 root      20   0       0      0      0 S   0.0  0.0   0:00.00 cpuhp/0
   13 root      20   0       0      0      0 S   0.0  0.0   0:00.00 cpuhp/1
   14 root      rt   0       0      0      0 S   0.0  0.0   0:01.50 watchdog/1
   15 root      rt   0       0      0      0 S   0.0  0.0   0:01.94 migration/1
   16 root      20   0       0      0      0 S   0.0  0.0   0:00.34 ksoftirqd/1
   18 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 kworker/1:0H
   19 root      20   0       0      0      0 S   0.0  0.0   0:00.00 kdevtmpfs
   20 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 netns
   21 root      20   0       0      0      0 S   0.0  0.0   0:00.58 khungtaskd
   22 root      20   0       0      0      0 S   0.0  0.0   0:00.00 oom_reaper
   23 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 writeback
   24 root      20   0       0      0      0 S   0.0  0.0   0:00.00 kcompactd0
   26 root      25   5       0      0      0 S   0.0  0.0   0:00.00 ksmd
   27 root      39  19       0      0      0 S   0.0  0.0   0:00.00 khugepaged
   28 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 crypto
   29 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 kintegrityd
   30 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   31 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 kblockd
   32 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 devfreq_wq
   33 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 watchdogd
   34 root      20   0       0      0      0 S   0.0  0.0   0:00.00 kswapd0
   35 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 vmstat
   47 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 kthrotld
   48 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 ipv6_addrconf
   84 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   85 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   86 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   87 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 ata_sff
   88 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   90 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   91 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   92 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
   93 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
  120 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
  121 root      20   0       0      0      0 S   0.0  0.0   0:00.00 scsi_eh_0
  122 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 scsi_tmf_0
  123 root      20   0       0      0      0 S   0.0  0.0   0:00.00 scsi_eh_1
  124 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 scsi_tmf_1
  126 root       0 -20       0      0      0 S   0.0  0.0   0:00.00 bioset
  157 root       0 -20       0      0      0 S   0.0  0.0   0:04.90 kworker/1:1H
  159 root      20   0       0      0      0 S   0.0  0.0   0:09.94 jbd2/vda1-8


References:

ps Man page

top Man page


Instructor Note

Instructor Notes.


7.4.2.8 which or whereis

  • The which command is used on Unix-like operating systems (such as Linux and macOS) to locate the executable file associated with a given command or program. It helps you find the path of the executable that would be executed when you type a command in the shell.

    • which [program] returns the pathnames of the files.

  • The whereis command is used on Unix-like operating systems to locate the binary, source, and manual page files associated with a command or program. It provides more comprehensive results than which by searching in multiple directories and locations.

    • whereis [program] locates the binary, source and manual files for the specified command names.


References:

which Man page

whereis Man page


Instructor Note

Instructor Notes.


7.3.2.9 Routing Table

Windows: route print
Linux/Unix: netstat -r (deprecated)
Linux/Unix: ip route


  • While end hosts are not routers, they do perform some routing functions within their capabilities. These functions are typically constrained to the following:

    • Inbound Routing Functions:

      • Destination Check: Does the packet’s destination match the host’s own IP address?

      • Forwarding Decision: If the packet is not destined for the host itself, does the host have knowledge of and access to the target? (Note: IP forwarding must be enabled for this to occur.)

    • Outbound Routing Functions:

      • Local Network Delivery: Is the target device on the same network as the host? If so, the packet is forwarded to the target’s local MAC address.

      • Remote Network Delivery: If the target device is on a different network, the packet is sent to the gateway’s MAC address, which will handle further routing.

  • Windows:

    • The route print command is used on Windows operating systems to display the current IP routing table. This table shows how network traffic is routed through the network interfaces of the computer.

route print

===========================================================================
Interface List
 13...00 1c 42 00 3f 1c ......Intel(R) Ethernet Connection (2) I218-V
  9...00 1c 42 00 3f 1c ......Intel(R) Wireless WiFi Link 5000 Series
===========================================================================
IPv4 Route Table
===========================================================================
Active Routes:
Network Destination        Netmask          Gateway       Interface  Metric
      0.0.0.0          0.0.0.0       192.168.1.1   192.168.1.100     10
    192.168.1.0    255.255.255.0       192.168.1.1   192.168.1.100     10
    192.168.1.1  255.255.255.255         On-link   192.168.1.100     10
===========================================================================
IPv6 Route Table
===========================================================================
Active Routes:
If Metric Network Destination      Gateway
  1    306 ::/0                     fe80::1
  1    306 2001:db8::/32             ::1
  1    306 fe80::/64                 On-link

  • Linux:

    • The netstat -r command is used on Unix-like operating systems (such as Linux and macOS) to display the system’s routing table. This table shows the routes that network packets take to reach their destination, including details about the network destinations, gateways, and interfaces.

      • -r (--route) - Display the kernel routing tables.

student@internet-host-student-01:~$ netstat -r
Kernel IP routing table
Destination     Gateway         Genmask         Flags   MSS Window  irtt Iface
default         10.10.0.62      0.0.0.0         UG        0 0          0 eth0
10.10.0.32      0.0.0.0         255.255.255.224 U         0 0          0 eth0

  • Linux:

    • The ip route command is part of the iproute2 suite of utilities used on Linux systems for managing network interfaces, routing tables, and more. It provides detailed information about the routing table, allowing you to view, add, delete, or modify routes.

student@internet-host-student-01:~$ ip route
default via 10.10.0.62 dev eth0
10.10.0.32/27 dev eth0 proto kernel scope link src 10.10.0.40


References:

ip Man page

netstat Man page


Instructor Note

Instructor Notes.


7.3.2.10 Find

  • The find command is used on Unix-like operating systems (such as Linux and macOS) to search for files and directories within a directory hierarchy based on various criteria. It is a versatile and powerful tool for locating files and performing actions on them.

find [where to start searching from] [expression determines what to find] [-options] [what to find] 2> /dev/null


student@internet-host-student-01:~$ find / -name passwd 2> /dev/null
/usr/bin/passwd
/usr/share/doc/passwd
/usr/share/bash-completion/completions/passwd
/usr/share/lintian/overrides/passwd
/etc/pam.d/passwd
/etc/cron.daily/passwd
/etc/passwd

  • / - specifies to start searching from system root.

  • -name pattern - Base of file name (the path with the leading directories removed) matches shell pattern pattern.

  • -iname pattern - Like -name, but the match is case insensitive.

  • filename - specify the name of the file to search for. Can use wildcards (*) before or after.

  • 2> /dev/null - removes error responses such as "Permission denied"


References:

find Man page


Instructor Note

Instructor Notes.


7.3.2.11 SSH Port

When accessing a target system via Telnet or a remote shell, you might not be immediately aware of the SSH port in use. Although tools like netstat or ss can list open and listening TCP ports, they may not reveal the specific port assigned to SSH, especially since SSH does not always default to port 22.

To accurately determine the SSH port, you should directly examine the SSH server configuration. This configuration is typically specified in the sshd_config file, which dictates the port on which SSH listens.

  • Linux: /etc/ssh/sshd_config.

    • grep ^Port /etc/ssh/sshd_config

  • Windows systems using OpenSSH: C:\ProgramData\ssh\sshd_config or C:\Windows\System32\OpenSSH\sshd_config.


References:

https://linux.die.net/man/5/sshd_config

https://learn.microsoft.com/en-us/windows-server/administration/openssh/openssh_server_configuration


Instructor Note

Instructor Notes.


7.4 Describe Methods Used for Active Internal Network Reconnaissance


800


Active Internal Reconnaissance looks very similar to Active External Reconnaissance and uses many of the same tools such as PING, NMAP and Netcat. They are employed in the same manner as Active External Recon except that the targeted addresses, ports, and services may be different.

Active internal network reconnaissance involves the proactive identification and probing of assets, systems, and vulnerabilities within an organization’s internal network. This phase is a crucial element of cybersecurity assessments, penetration testing, or ethical hacking conducted within the internal network environment. In comparison to passive reconnaissance, which entails observation without direct interaction, active internal network reconnaissance utilizes a variety of tools and techniques to actively deploy probes, requests, and queries for gathering information and evaluating potential weaknesses.

In this phase we will commonly used commands on the local system to probe or interact with other systems on the internal network. With SSH Tunneling, we can leverage tools on our local system to route our traffic through the internal system, enabling us to examine or engage with internal systems.


References:


Instructor Note

Instructor Notes.


7.4.1 ARP Scan

As we have learned before, ARP is used to resolve IP addresses to MAC addresses. By exploiting this protocol, we can learn the IPs an MAC addresses of devices in the local network segment. The responses that return are only for the local segment, so the requests must be run internally from the desired location. This is a low level scan that can potentially be overlooked on many networks.


  • ARP Scanning

sudo arp-scan --interface=eth0 --localnet

sudo arp-scan --interface=eth0 10.1.0.0/24

arping –c 1 –i eth0 172.16.32.2 (can only scan a single host, results vary)

for ip in $(sew 1 254) ; do if ping -c 1 10.1.0.$ip>/dev/null; then echo "10.1.0.$ip UP"; fi ;done

nmap –PR 172.16.32.2(legitimate scan that often does not show results)

nmap -PR -6 fe80::f816:3eff:fed9:5116/64(takes a long time to run)


References:

arp-scan Man page


Instructor Note

Instructor Notes.


7.4.2 PING Scan

A PING scan, also known as an ICMP Echo scan or simply a Ping scan, is a type of network reconnaissance technique used to determine the reachability of hosts on a network. It works by sending ICMP Echo Request packets (PING) to a range of IP addresses and listening for ICMP Echo Reply packets (PONG) that are returned by live hosts.


ping -c 1 172.16.82.106

for i in {1..254}; do (ping -c 1 172.16.82.$i | grep "bytes from" &) ; done

sudo nmap -sP 172.16.82.96/27


References:


Instructor Note

Instructor Notes.


7.4.3 /DEV/TCP

/dev/tcp is a special virtual filesystem in Linux that provides access to TCP sockets as if they were files. It allows you to create client or server connections to remote hosts using Bash shell commands or scripts, without the need for external utilities or libraries.

Performing TCP scanning using /dev/tcp in Bash is not directly supported because /dev/tcp is primarily used for creating client connections to remote hosts, not for scanning multiple hosts and ports. However, you can create a script in Bash to perform TCP scanning using /dev/tcp for a single host and port.

One of the advantages about /dev/tcp is that it can be used without root level privileges. This can allow the ability to perform a TCP port scan on a network when other tools like NMAP or Netcat are not available.

Since /dev/tcp is normally installed by default of most Linux systems with the Bash shell, this can a major vulnerability and a possible tool to use in reconnaissance.

  • Banner Grabbing with /dev/tcp

    exec 3<>/dev/tcp/tgt_ip/tgt_port; echo -e "" >&3; cat <&3

    • exec 3<>/dev/tcp/tgt_ip/tgt_port: Opens a file descriptor (FD) 3 for reading and writing to the specified hostname and port using /dev/tcp.

    • echo -e "": Sends data to the port to interogate it.

    • cat <&3: Reads the response from the server on file descriptor 3 and displays it on the console.

  • To conduct a portscan using /dev/tcp.

    • One-liner:

      for p in {1..1023}; do(echo >/dev/tcp/172.16.82.106/$p) >/dev/null 2>&1 && echo "$p open"; done

    • Script:

      #!/bin/bash
echo "Enter the IP address you want to do a full port scan on."
read address
rm $address.txt
for p in {1..65535};
do
      timeout 1 bash -c "echo >/dev/tcp/$address/$p" >/dev/null 2>&1  &&
      echo "$p open" >> $address.txt ||
      echo "$p is closed"
done
cat $address.txt

  • This script prompts the user to provide a single IP address to run a full port scan on.

  • It removes any previous output files ran by the script with the same IP address.

  • It iterates through all avalable ports and then reports all reachable ports as "is open" and all closed ports as "is closed".

  • It saves the open ports results to a file and cats the contents of that file after the script completes.


References:

Advanced Bash-Scripting Guide: Chapter 29. /dev and /proc

/dev/tcp as a weapon


Instructor Note

Instructor Notes.


7.5 Perform Network Forensics


References:


Instructor Note

Instructor Notes.


7.5.1 Map a Network

Map a network through correlation of relevant network artifacts gathered through Reconnaissance and analysis

Mapping a network refers to the process of discovering and documenting the devices, resources, and topology of a computer network. This includes identifying all devices connected to the network, such as computers, servers, routers, switches, printers, and other networked devices, as well as understanding the relationships between these devices and how they communicate with each other.


  • Networks can be very small (1 or 2 systems) to very large (1000+). Visualizing the network can be very challenging.

  • Creating a physical map of the network is very valuable to Network Defenders for troubleshooting but this information can be a huge vulnerability if this information falls into the wrong hands.

  • Understanding how to create a Network map is invaluable.

  • The concepts below will be crucial for the rest of the course activities and exercises.

  • Different units and missions may require accompanying documents to your network map(s) and network map standards may vary between units in addition to whether you are offensive or defensive.


Offensive Mapping:

  • Diagram devices - Use specific images/drawings for different devices. Depending on the data available it may not be possible to see all devices on the network for a variety of reasons such as the layer that a device functions at, or where a device is located in a network.

    • Routers - Image to depict different vendors/models.

    • Switches - This type of device is often not seen offensively due to the layers that they function at.

    • Hosts - Image to depict desktop/laptop or operating system.

    • Servers - Should be classified separatly from hosts. Knowing where and what servers are can provide additional context and information for future planning.

    • Firewalls - These provide more powerful filtering compared to router ACL’s.

    • Clouds - This pertains to both cloud services utilized and elements outside of the target network.


Map


  • Types of lines:

    • Solid - Direct connection between devices

    • Dashed - Devices are able to talk but it has not been confirmed that they are directly connected i.e. there is a chance of a device between them.


Map


  • Additional Written Information - This is information that should accompany devices and additional groupings

    • Device names - Naming schema allows you to confirm what machine you are on and often tells you how many devices/ what unidentified devices may be called.

    • IP address and MAC address - needed to directly address specific device.

    • Number and types of interfaces - Systems with more than one interface means that it can potentially be connected to several networks. This system can be a potential pivot system.

    • Operating system - Identify the OS, version and patches applied. This will potentially lead to possible vulnerabilities and exploits.

    • Versions/patches - This will help identify security features, functions, and vulnerabilities available.

    • Credentials - usernames and passwords to access the system.

    • Ports/Services - all open service ports on system.

    • Protocols running - Other than TCP/UDP it may be useful to know if ICMP is allowed/running. Identify any other protocols discovered.


  • Device Coloring:

    • Red - Non viable target

    • Yellow - Possible target; non verified credentials or possible exploitable vulnerability

    • Green - Valid target with verified credentials or exploitable vulnerability


Map


  • Additional Groupings:

    • Routing Protocols

    • VLANS

    • NAT boundaries

    • Tunnels

    • Job Role


Map


References:

Draw.io Map Template

network Diagram 101

https://app.diagrams.net/

https://app.diagrams.net/

https://draw.chat/

https://cloud.smartdraw.com/

https://app.ziteboard.com/

https://app.ziteboard.com/

https://www.tutorialspoint.com/whiteboard.htm

https://whiteboard.explaineverything.com/


Instructor Note

Instructor Notes.


7.6 Network Recon Methodology

What we need to do:

  1. Gather initial information ( inital access ip address and port(s) )

  2. Determine the network range ( /16, /20, /24, /27 )

  3. Identify active machines ( ping or port scan )

  4. Discover open ports and access points ( port scan)

  5. Fingerprint the operating system ( banner grab ports or sniff traffic )

  6. Uncover services on ports ( banner grab open ports )

  7. Map the network ( physically draw network starting from your system and build a tree view )


How we go about doing it:


  • 1. Conduct Passive recon on your (or remote) system (if needed)

    1. ip addr (ipconfig/ifconfig) - this will show all interfaces and IP address as well as MAC, CIDR and Broadcast

    2. use reverse subnetting to determine the network range (first - last IP) from the IP/CIDR.

      1. 10.10.0.40/27

        1. Network = 10.10.0.32

        2. Usable range = 10.10.0.33 - 10.10.0.62

        3. Broadcast = 10.10.0.63

    3. ip neighbor (arp -a) - will display any systems that the local system has communicated with recently.

      1. may show some systems but any systems it has not communicated with will not be in the database.

    4. ss (netstat) - display any tcp/udp listening ports.

      1. use to see all TCP/UDP ports listening on 0.0.0.0.

      2. May see ports that you did not see from active scanning.

    5. ps -ef - identify any services/daemons sunning on system.

      1. look for specific services like running processes, firewall, or IDS/IPS software.

    6. find - use to search for specific files/folders.

      1. find / -name name 2> /dev/null

      2. find / -iname name 2> /dev/null

      3. * are wildcards that can be used before/after a name

    7. share folder (/usr/share/cctc) - any files stored on system

    8. tcpdump/Wireshark - (if accessible) to sniff traffic.

    9. use 'which' or 'whereis' to identify any other programs installed on system with their binary paths.


  • 2. Conduct Active recon (scan) from your box to find other systems on the same network.

    1. ./scan.sh or nmap - scan from your box

    2. proxychains ./scan.sh or proxychains nmap - scan thru dynamic tunnel to enumerate from proxy.


  • 3. Conduct Network Forensics

    1. Identify IP address, TCP/UDP ports you find and document them on your network map.

    2. Create a tree view map with your system being the root and each system accessible from your box as branches.

    3. Enumerate TCP and UDP ports to identify services running on the them.

      1. Interact with services you see (FTP, curl, wget, firefox, NC, etc).

        1. FTP(21) or HTTP(s) (80/443) you can use

          1. curl http://10.0.0.1 or curl ftp://10.0.0.1

          2. wget -r http://10.0.0.1 or wget -r http://10.0.0.1:2000 or wget -r ftp://10.0.0.1

        2. ssh (port 22)

        3. telnet (23)

        4. banner grab other ports

          1. nc 10.0.0.1 1111

          2. telnet 10.0.0.1 2222

      2. Pull files using scp.

        1. scp student@10.0.0.1:/usr/share/cctc/flag.png .


  • 4. Review collected data from the systems (review file information and clues)

    1. systematically download all data to your system to analyze and record.

    2. Identify any possible pivot system(s) you can use to find more systems. (needs SSH or Telnet access)

    3. does any system have either ssh or telnet open to pivot thru?


  • 5. Conduct Active Enumeration

    1. Remote to pivot (if applicable)

    2. Conduct passive recon on the pivot box (same as step 1). Is it a viable pivot?

    3. (Back on your box) Build a tunnel to pivot (with -D, -L or -R if needed)

      1. Build Dynamic Tunnel to pivot.

        1. ssh user@ip-address -D 9050

      2. Build a Local or Remote.

        1. Your-box$ ssh user@ip-address -L 1111:next-pivot-ip:22

        2. Remote-box$ ssh user@ip-address -R 1111:localhost:22


  • 6. Conduct Active recon (scan through Proxychains) from your box to find other systems accessible from your new pivot.

    1. proxychains ./scan.sh - scan thru dynamic tunnel to enumerate from proxy.


  • 7. Conduct Network Forensics

    1. Identify IP address, TCP/UDP ports you find and document them on your network map.

    2. Create the additional tree "branches" on your map.

    3. Enumerate TCP and UDP ports to identify services running on the them.

      1. Interact with services you see using proxychains (FTP, curl, wget, NC, ssh, telnet, etc)

        1. FTP(21) or HTTP(s)(80/443) you can use

          1. proxychains curl http://10.0.0.1 or proxychains curl ftp://10.0.0.1

          2. proxychains wget -r http://10.0.0.1 or wget -r http://10.0.0.1:2000 or proxychains wget -r ftp://10.0.0.1

        2. proxychains ssh (port 22)

        3. proxychains telnet (23)

        4. banner grab other ports

          1. proxychains nc 10.0.0.1 1111

          2. proxychains telnet 10.0.0.1 2222

      2. Pull files using scp.

        1. proxychains scp student@10.0.0.1:/usr/share/cctc/flag.png .


  • Repeat from step 4.


  • Additional guidance:

    1. Windows (terminal) management. You will have many tunnels open so you need to keep it organized. Rename windows to help organize.

    2. File management. You will pull many artifacts back to your system. We need to organize them so you know where each file was pulled from and relates to. (wget -r can help with this). You can also use pcmanfm command thru a -X ssh session to open the system file manager to navigate the file system with a GUI.

    3. Create a physical map of the network and markdown information you find (as you find them).

    4. Take Op-notes on what you are doing, the systems you interfaced with, the information you collected, tunnels you created, things you tried, and things that may have failed.


References:

https://www.techtarget.com/searchsecurity/feature/Network-reconnaissance-techniques-for-beginners

https://medium.com/@realm3ter/my-recon-methodology-ep-1-bc9e6fd660ad

https://www.blumira.com/glossary/reconnaissance

https://labex.io/tutorials/cybersecurity-how-to-perform-network-reconnaissance-418241

https://medium.com/@jaber_5689/basic-reconnaissance-techniques-gathering-information-ethically-dc186555bfc9


Instructor Note

Instructor Notes.


ACTIVITY: Donovian Mapping & Reconnaissance (DMR)
